Product Overview

Description

Description

Ceramic Heater Elements is efficient, robust heaters which provide long wave infrared radiation. They are used in a diverse range of industrial processes such as heaters for thermoforming, and as heaters for paint curing, printing and drying. They are also used very effectively in infrared outdoor heaters and infrared saunas.

It has many kinds of shapes, contains flat elements, trough elements, hollow



Specification

1,Nickel chrome resistance wire(NiCr20/80)

2,Color: White/Black

3, Type K thermocouple mounted internally in center heater. Optional type J thermocouple is also available.

4,Heater Voltage: 120V 220V 230V 240V 480V standard (other voltages available on request)

5,Useful wavelength range: 2-10 microns

6,Operating temperature is 300°C to 700°C (572°F - 1292°F)

7,Average Operating Life-Up to 20,000 hrs depending on conditions.

8. Recommended radiation distance from heater is 100 mm to 250 mm.

9,Supplied with 100mm ceramic beaded power leads



Detailed Power Specifications

Size(mm)	Type	Power
60*60	Curved/flat/Hollow	Available in 125w and 250w
122*60/120*60	Curved/flat/Hollow	Available from 125w to 500w
122*122/120*120	Curved/flat/Hollow	Available from 150w to 750w
245*60	Curved/flat/Hollow	Available from 150W to 1000w
245*80	Curved/flat/Hollow	Available from 150w to 1000W



Applications

Ceramic heater can be widely used in vacuum forming, dry food, medical treatment sanitation etc kinds of places of infrared dry firing, solidify etc. It has perfect saving energy effect in electron, textile , light industry, chemical , medicine ,food industry etc, has obvious social profit and economy profit.



Advantage

1.Low MOQ: It can meet your promotional business very well.

2.OEM Accepted : We can produce any your design as long as you provide us the drawing.

3.Good Service : We treat clients as friend.

4.Good Quality :We have strict quality control system .Good reputation in the foreigner market

5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract)
