1 24 часовой пояс регулятор температуры K/J Тип Pid температуры обогреваемого литника коробка для литья под давлением
- Category: Mould Temperature Controller >>>
- Supplier: Xiamen Mach Cnc Machining Master Co. Ltd.
Share on (60773229310):
Product Overview
Description
Product Type | hot runner temperature controller |
Zones | 1~24,or customized |
Power Supply | AC86~ 240V, 50/60HZ, 50/60HZ Hot runner timing controller |
Sensor Type | Thermocouple J or K |
Temperature Accuracy | ±0.5℃ |
Working Temperature | 0~55℃(32~131℉) |
Temperature Range | 0~450℃(32~860℉) |
Control Functi | Auto / Manual |
Input Type | DC24V / AC220V |
Output Type | Bidirectional Thyristor 15A 220V AC 3600W |
Accuracy | 0.01s |
PCB Composition | Controller PCB and Display PCB |
Features:
1. Wide power supply range, AC86~240V
2. Thermocouple input protection, prevent module damaged by mis-connection
3. Thermocouple & heater inverse protection, prevent thermocouple damaged by mis-connection
4. The temperature control error is 0.5 degrees, FUZYY+PID control algorithm, PID parameter has two ways: online automatic setting
and manual setting.
5. The output power shows that the output power can be automatically detected during heating.
6. With the hot runner soft start heating mode, the heat flow dehumidification effect is realized, the heating pipe can be
protected to prolong the service life effect, the soft start heating power and the heating time can be set freely.
7. Two kinds of K and J type thermocouple sensor signals can be set. The precise temperature nonlinear processing and integrated
cold end compensation control mode is zero crossing trigger mode, PWM pulse width modulation output
8. There are two ways to set and display the temperature and the degree of Fahrenheit.
9. Temperature upper limit alarm function, temperature lower limit alarm function, upper / lower limit temperature can be set.
10. Besides automatic control, the system is equipped with manual control mode for heating in special cases.
Diagnostic Functions
Alarm when the followings occurred
1. Ultra-high or ultra-low Temperature
2. Thermocouple break, short or inverse
3. Thermocouple is out of its position
4. Heater break, short or overload
5. Output device is damaged
1. Wide power supply range, AC86~240V
2. Thermocouple input protection, prevent module damaged by mis-connection
3. Thermocouple & heater inverse protection, prevent thermocouple damaged by mis-connection
4. The temperature control error is 0.5 degrees, FUZYY+PID control algorithm, PID parameter has two ways: online automatic setting
and manual setting.
5. The output power shows that the output power can be automatically detected during heating.
6. With the hot runner soft start heating mode, the heat flow dehumidification effect is realized, the heating pipe can be
protected to prolong the service life effect, the soft start heating power and the heating time can be set freely.
7. Two kinds of K and J type thermocouple sensor signals can be set. The precise temperature nonlinear processing and integrated
cold end compensation control mode is zero crossing trigger mode, PWM pulse width modulation output
8. There are two ways to set and display the temperature and the degree of Fahrenheit.
9. Temperature upper limit alarm function, temperature lower limit alarm function, upper / lower limit temperature can be set.
10. Besides automatic control, the system is equipped with manual control mode for heating in special cases.
Diagnostic Functions
Alarm when the followings occurred
1. Ultra-high or ultra-low Temperature
2. Thermocouple break, short or inverse
3. Thermocouple is out of its position
4. Heater break, short or overload
5. Output device is damaged
