| Product Name | Disc Harrow Blades for Cultivator |
| Material | 86B40,86B30,custom |
| Finishing | Anti-rust, Spray Paint, Power Painting, Galvanized |
| Hardness | 45-52HRC, or custom |
| Application | Cultivator , grass , ridging and field work tool |
| Specifications of Disc Harrow Blades | ||||
| Diameter | Concavity | Thickness | ||
| MM | INCH | MM | INCH | MM |
| 305 | 12 | 19 | 3/4 | 3 |
| 330 | 13 | 25 | 1 | 3 |
| 355 | 14 | 38 | 11/2 | 3 |
| 410 | 16 | 38;47;51 | 1 1/2;1 7/8;2 | 3;3.5 |
| 430 | 17 | 57 | 2 1/4 | 3;3.5;4 |
| 460 | 18 | 38;44;57;59 | 1 1/2;1 3/4;2 1/4;2 5/16 | 3;3.5;4 |
| 480 | 19 | 57 | 2 1/4 | 3.5;4 |
| 510 | 20 | 44;51;57;63 | 1 3/4;2;2 1/4;2 1/2 | 3.5;4;5 |
| 535 | 21 | 63 | 2 1/2 | 3.5;4;5 |
| 560 | 22 | 63;70;76;83 | 2 1/2;2 3/4;3;3 1/4 | 3.5;4;5;6 |
| 585 | 23 | 83;89 | 3 1/4;3 1/2 | 3.5;4;5;6 |
| 610 | 24 | 76;81;83;89;95 | 3;3 3/16;3 1/4;3 1/2;3 3/4 | 3.5;4;5;6 |
| 660 | 26 | 86;89;102;108;114 | 3 3/8;3 1/2;4;4 1/4;4 1/2 | 5;5.5;6;7;8 |
| 710 | 28 | 102;108;114;127;130 | 4;4 1/4;4 1/2;5;5 1/8 | 5;5.5;6;7;8 |
| 760 | 30 | 121;133 | 4 3/4;5 1/4 | 6;7;8;10;11 |
Note:The technical parameters can be in accordance with the requirements of customers production.
