Intel H87 8 LAN 1U Rackmount Linux UTM Firewall Hardware Appliance Network Security Router Appliance
- Category: Firewall & VPN >>>
- Supplier: Yentek (shenzhen) Technology Co. Ltd.
Share on (60774687578):
Product Overview
Description
Intel IoT Solution Alliance Affiliate Member
Intel Intelligent System Alliance Member
ISO9001:2008 Quality Management Certified
ISO14001:2004 Environmental Management Certified
National High Tech Enterprise With Procssional R&D Team
Intel H87 8 LAN 1U Rackmount Linux UTM Firewall Hardware Appliance Network Security Router Appliance
Product Description
Features
Fan cooling fin structure
High quality galvanized steel plate, compact structure, flexible installation
Support LGA1150 4th gen Intel Core i7/i5/i3/Pentium/Celeron processor
1xVGA, 2xUSB2.0, 1xCISCO COM
Adopt 82574L chipset,support 8* Gigabit Ethernet, 4* Intel 82580EB 1000Mbs fiber port
Dimension:430mm*360mm*44.5mm
Specification
| Model No. | R870LZ | |
| Chassis | Color | Black |
| Dimension | 430mm*360mm*44.5mm | |
| Structure | 1U Standard chassis | |
| Material | High quality galvanized steel sheet | |
| Installation | 1U standard rack mounting method | |
| Motherboard | Model | H87SL_B |
| Processor | Support LGA1150 Intel® Core® i3/i5/i7 processor | |
| Chipset | Adopt Intel® H87 high speed chipset, compatible H81 series chipset | |
| Graphics | Integrated Intel® HD Graphics 4000, support 1*VGA display output | |
| Storage | Memory | 2* DDR3 memory slot, support 1600/1333MHz, max up to 16GB |
| HDD | Support 2*2.5" / 1*3.5’ HDD expansion | |
| CF | N/A | |
| SSD | Support 1*MSATA SSD expansion | |
| Audio | Sound Card | N/A |
| Network | Ethernet | 8* LAN (Intel 82574L, 1000/100/10Mbps) 4* Intel 82580EB 1000Mbps fiber interface / ethernet port |
| WiFi | N/A | |
| I/O Port | Serial Port | 1* CISCO standard RS232 serial port |
| USB | 2* USB2.0 | |
| LAN | 8* RJ45 Gigabit Ethernet Port | |
| Expansion | 4* Fiber interface | |
| Power Switch | 1*Power switch | |
| LED | 1* HDD LED, 1* Power HDD, 4*Fiber Data LED, 4* Fiber Link LED | |
| Display | 1* VGA display output | |
| Power Supply | 1* ATX Power Interface | |
| Power Supply | Input | AC 110V ~ 220V |
| Output | AC 110V ~ 220V | |
| Type | ATX power supply | |
| Reliability | Operating Temp. | 0℃~45℃ |
| Storage Temp. | -20℃~70℃ | |
| Relative Humidity | 5%-95%, no condensing | |
| Vibration | 0.5g rms/5-500HZ/random/operating | |
| Operate System | Support Windows7, Windows8, Windows10, Linux | |
Order No.
| No. | Model | CPU structure | Processor | Motherboard | Memory | SSD | LAN | Optical Port | COM | USB | Power Supply | System |
| 1 | R870LZ | LGA1150 | / | H87SL_B | / | / | 8*82574L | 4*82580EB | 1 | 2 | 220W | / |
Company Information
YANYUGONGKONG
MEMBER OF INTEL® INTELLIGENTSYSTEMS ALLIANCE, is a R&D and manufacturing technology-innovation enterprise specialized in Industrial Motherboards and embedded products.
Our products include:mini-itx motherboard,all-in-one motherboard, 3.5'' industrial motherboard,
firewall motherboard, NVR&industrial motherboard, Mini PC , HTPC,All-in-one PC,
Embedded PC ,Vehicle computers,Cloud Terminal,Networking Security,OPS Mini PC
Computer,OEM / ODM available.
Packaging & Shipping
1.Delivery Time: 1 ~ 3 Days for one sample, 5-7 Working days for a large quantity.
2.Packaging Ways: Each pc for one neutral box, ten or sixteen neutral box for one carton.
3.Shipping Ways: For small amount, we advise our customer to take DHL, Fedex, UPS.
For a large quantity, we can support to ship by air or by sea.
Our Services
1. As a professional manufacturer/ OEM Factory and supplier of mini pc/ motherboard,firewall appliance over 11 years,Affinicate member of intel League.gain greatly supports from intel.And we win our customers with good quality,best service and factory price.
2.Our products are 100% original and have strict QC inspection before shipment.
3.Professional and efficient sales team to serve for you diligently.
4.Sample order is welcomed and will be delivered within 1-3 days.
6.We support Trade Assurance to ensure On-time shipment and product quality.
7.We provide OEM/ODM service according to your requirements.
8.We provide 3years maintenance warranty for our products.
1. Do you provide OEM/ODM service?
A: Yes,.We can support OEM/ODM service, the process of customization is following:
1) provide your specific requirement.
2) our design engineer draw the design draft.
3) you confirm the design draft.
4) we start produce it.
2. What is the Minimum Order Quantity (MOQ)?
A: We can sell one piece sample for your test.
3. What payment method do you use?
A: T/T,Western Union,PayPal.
4. What is the lead time of your product?
A: 3 days for sample, 15 working days for large quantity.
5. How does your factory do related quality control?
A: Quality is top priority. We firstly check the motherboard quality after manufacturing, secondly check the computer before storage in warehouse and thirdly check before shipping out.
6. What is the warranty time of your product?
A: 1 year warranty for non-artificial damage, for the 2nd to 3rd year we can repair it free, but will charge for the parts that needed to change.
7. Does your motherboard can work keep working 24*7 hours?
Our low power consumption industrial boards have passed very strict tests, there is no problem to keep working 24*7 hours.
8. Are you a factory or trading company?
A: YANYUGONGKONG
MEMBER OF INTEL® INTELLIGENTSYSTEMS ALLIANCE, is a leading R&D and manufacturing technology-innovation enterprise specialized in Industrial Motherboards and embedded products industry.
Our products include: mini-itx motherboard,all-in-one motherboard, 3.5'' industrial motherboard, firewall motherboard, NVR&industrial motherboard, mini PC , HTPC, all-in-one PC, embedded PC, vehicle computers, cloud terminal, networking security, OPS mini PC, NAS server, etc.
Computer, OEM / ODM available.
9 If we come to China, can you arrange the visiting to your factory?
A: We warmly welcome and look forward to your visiting to our factory at any time.
