Product Overview

Description

Product Description

Product Application of High Precision Cast Iron Inspection Table :

Cast iron plate, also known as cast iron platform, appearance is basically a box type, such as rectangle, square, round face, materials as HT200-300, QT400-600,using as research process, can be processed on the working plane V, T, u-shaped slot, dovetail groove, long round hole, hole, etc., Used for workpiece, equipment testing, marking, assembling, welding, assembling, plug welding, flat benchmark measuring tool.

SPECIFICATIONS FOR High Precision Cast Iron Inspection Table

Surface
Flat or V, T, straight-shaped slots and tapped holes, long holes, grid lines as need
Treatment
Hand-scraped, finish-milling or ground finish
Hardness
HB170-240
Materials
High-strength cast iron, HT200-300
Type
100*100~3000*8000mm or customize
Precision Grade
0, 1, 2, 3 Grade
Working Temperature:(20±5)℃
Casting
Sand casting
Resin sand molding
