Detall electronics laboratory table equipment lab furniture

Product Description



detall esd workbench (2).jpg

17Product Introduction

The towerline ESD workbench is a specific type of workbench which adopt the structure of table together with the double slotted Upright frame supporter . it is able to allow the work surface or the optional modular accessories to be mounted on either side of both the single sided and double sided station, and adjustable on workstation along column.

ESD Towerline workbench is suitable for electronics and semiconductor industries , military-industrial , aerospace sectors, contract manufacturers, research and educational organizations and telecommunication industries.

SPECIFICATIONS FOR Detall electronics laboratory table equipment lab furniture



Size
length
mm
1200/1530
Deepth
mm
600/750
Height
mm
785mm (table top to ground)
760-1120 (adjustable type)


Main performance parameters
ESD performance parameters
ohm
(test input 100V, )
metal surface: 105 - 1010
Laminate surface: 106 - 1010
Static weight loading
KG
300kg - light duty type
500kg - standard duty type
800kg - heavy duty type



Extensible structure

In order to increase the functions and storage space of the workbench, Detall design the workbench's system be divided into different structure, maximum the numbers and variety of functional accessories, the design maximum extends the functions of the workbench.
The workbench is divided into1. 2 or 3 column by the double slotted Upright frame supporter to add the max quantity of accessories on the columns.

High Standard of Detall electronics laboratory table equipment lab furniture - CE certificated
EN ISO 12100:2010
Safety of machinery - general principles for design -  risk assessment and risk reducion
EN 60204-1:2006 +A1:2009 +AC:2010
Safety of machinery - Electrical Equipment of machnies - part 1: Gerneral requirments
IEC 61340-5-1:2007
Electrostatics - Part 5-1: Protection of electronic devices from electrostatic phenomena
Electrical Properties of Detall electronics laboratory table equipment lab furniture
Test
Relative Humidity
Electrical Results


Point to point resistance
60%-40%
106 to 1 x 107 ohms
40%-20%
107 to 1 x 108 ohms
20%-10%
108 to 1 x 1010 ohms


Point to earth resistance
60%-40%
106 to 1 x 107 ohms
40%-20%
107 to 1 x 108 ohms
20%-10%
108 to 1 x 1010 ohms

Volume Resistance
60%-30%
107 to 1 x 108 ohms
30%-10%
108 to 1 x 1010 ohms

Static Decay
50%
0.01sec
10%
0.02sec
1. Per EOS/ESD - S 4.1
2. Measured Face to Back at 72°F, 100 V with a LCD Megohmmeter, Item No. 19770,NFPA Electrodes (2.5 inch diameter, 5 pounds)
3. FTMS 101C, Method 4046
