AV4023 1MHz ~ 18GHz Handheld Microwave Spectrum Analyzer

Product Overview

Description

Product Overview
AV4023 Handheld Microwave Spectrum Analyzer is the new generation handheld microwave
spectrum analyzer using broadband microwave component integration design technology,

microwave multilayer PCB design technology, efficient voltage transformation system design

technology and multi-band sweep & individual thread processing technology. Compared with

the last generation product, its frequency range increases by 5 times, display average noise

level decreases by 20dB, single sideband phase noise decreases by 20dB and measuring

speed increases by 4 times, featured by broad frequency band, high performance
index, small size, light weight, flexible power supply and easy maneuvering, suitable for field
service.

Available in the frequency range 1MHz ~ 18GHz, AV4023 Handheld Microwave Spectrum
Analyzer can meet the need of measurement from short-wave through to wave band Ku. It uses
menu-type operation interfaces and graphical display of measurement result, which operation is
simple and result is direct viewing. Handheld microwave spectrum analyzer is internally built with
a large-capacity FLASH memory and supports USB external memory by which the field
measurement curves can be stored for subsequent analysis and processing and filing up for
management.

AV4023 Handheld Microwave Spectrum Analyzer is mainly used in the development, repair and
maintenance etc. various sectors of radar and communication equipment as well as by the
spectrum monitoring and management department for spectrum monitoring and management.



Main Features
High measurement speed
Abundant measurement functions
Support both linear sweep and list sweep
Chinese/English menu for easy use
Available in battery power, convenient for field service

Built-in large-capacity memory and USB external memory extension supported
Intelligent battery management function, as long as 4 hours battery service life



AV4023 Handheld Microwave Spectrum Analyzer can easily realize fast and efficient signal
detection and measurement no matter in laboratory or in field.



High measurement speed
The minimum sweep time is only 600ms at 18GHz span.





Abundant measurement functions
In addition to spectrum measurement function,it also has the functions of occupied bandwidth

measurement, channel power measurement, adjacent channel power measurement, etc





Field intensity measurement function
The field intensity measurement function can position the interference signal by measuring
its field intensity; and allows users to edit the antenna factor





Support both linear sweep and list sweep
The list sweep mode can help users easily realize fast measurement of sub-band.





Chinese/English Menu for easy use
This instrument is available in menus in Chinese and English versions, the switching between
which can be realized by one button conveniently



Built-in large-capacity memory and USB external memory extension supported
AV4023 Handheld Microwave Spectrum Analyzer is internally built with a large-capacity memory
and supports USB external memory extension, which can meet the requirements of trace storage
in field measurement





Typical Applications
In the case of complex field measurement under special testing environment, AV4023 Handheld
Microwave Spectrum Analyzer can realize fast measurement of microwave signals, its features of high
measurement speed, high measurement accuracy etc. allow it to meet the needs of spectrum
monitoring and management departments for spectrum monitoring and management and render it a
broad application prospect in mobile communication and radio & television, etc. fields.
