FY 200R Medical Analog X Ray Machine Imaging Machine

Parameter

FY-200R

FY-500R

Intermittent mode

100kV ,200mA,20kW

100kV ,500mA,50kW

Power Voltage

Three-phase five wires 380V±38V

tube current

Radiography16mA~200mA

Radiography16mA~630mA

Output Voltage

Radiography 40-125KVstep 1kV

resistance power

less than 0.5Ω

Output power

20kW

50kW

Exposure Time

Radiography 0.0025s~6.4s adjustable

Nominal Frequency

≥30kHz

Anode speed

2800r/min

Anode heat capacity

140KHU

Focus

Small focus:1.0mm

Large focus:2.0mm

L*W*H of bed surface

2100mm×825mm×650mm

Horizontal moving range

≥250mm

Vertical moving range

≥825mm

grid density

≥40 lines/cm.

grid ratio

10:01

Focus Distance

100cm

Cassette size

5″×7″   8″×10″   10″×12″   11″×14″   14″×17″
