Product Overview
Description
Commercial Portable Ice tube Maker
According to your requirements to set ice making machine,it is automatic cleaning,automatic disinfection time and cycle tips, safe and secure.
Hot Sale Crystal Clear ICE Maker Edible for Bar/Home/Restaurant/Cola
Product Description
Model: KMG-3T
Standard Working Condition: Ambient Temp: 25℃, Water Inlet Temp: 20℃
Applicable Condition: Ambient Temp: 5℃-40℃, Water Inlet Temp: 5℃-40℃
Optional tube ice size(diameter):@22,@29,@35,@38,@41
Refrigerant Applicable:R22,R404A,R507
The air-cooled mode is also applicable.
Applicable Condition: Ambient Temp: 5℃-40℃, Water Inlet Temp: 5℃-40℃
Optional tube ice size(diameter):@22,@29,@35,@38,@41
Refrigerant Applicable:R22,R404A,R507
The air-cooled mode is also applicable.
Product Description
| Parameters | Technical data | |
| Daily output | 3tons/day | |
| Weight | 1500kg | |
| Measurement | Tube ice machine | Machine: 1400 x 1200 x 2300mm |
| Cooling tower: Diameter:1170mm Height:1690mm usually install in the outside | ||
| Tube ice | Diameter: 16mm,22mm,28mm,35mm | |
| Noise | 55dB | |
| Evaporating temp. | -15℃ | |
| Condenser temp | +40℃ | |
| Necessary cooling capacity | 24.2kw | |
| Input water temp. | 23℃ | |
| Ambient temp. | 40℃ | |
| Compressor | Model | semi-hermetic compressor |
| Brand name | Bitzer | |
| Amount | 1 | |
| Type | 4NCS-12.2 | |
| Capacity | 9.58kw | |
| Power of cooling tower motor | 0.56kw | |
| Power of cooling water pump | 1.5kw | |
| Power of circulating water pump | 1.1kw | |
| Power of ice cutter | 0.75kw | |
| Evaporator | Type | tube type |
| Diameter | 32mm | |
| Control system | PLC micro-computer control | |
| cube ice weight density | 500~550kg/m3 | |
| Power consumption | 80kw~85kw/ton | |
Packaging & Shipping
1. packed by standard export wooden box
2. shipping terms: FOB Shenzhen,China or CIF your Port
Our Services
We provide 12months warranty and free parts within warranty period
After shipment, we will send you the user manual of ice machine
