Product Overview

Description





• Sophisticated circuitry with sampling frequency of 640MHz makes it possible to reflect and analyze the echo signals of the flaw rapidly and accurately to detail, which guarantees the real-timeness and actuality of the echo signals.
• Advanced square drive technique renders it wonderfully penetratable and signal-effective in high-attenuating materials or thick industrial works. Adjustable drive pulse width, drive voltage and damping collectively contribute to its high resolving power while detecting on thin works and composite materials.
• FIR digital filtering technique realizes its great signal-effectiveness; Frequency spectrum analysis function differentiatablizes transducers.
• The EL screen(320X240),which is widely tolerant to temperature variants and highly refleshable in display, enables the CTS-9002+ to work in severe cold.
• Long consecutive record and storage In accordance with EN12668-1:2000 and Item TSG R0004-2009 of New Pressure Vessel Stipulation.
• Automatic calibration on the field velocity, delay, K value of the transducer; convenient development and application of DAC and AVG figure.
• SD card port for mass storage; USB port for external connection with U disk, keyboard and mouse to realize IT communication, data exchange and paper-borne output.
• Ergonomics-optimized structure and appearance with muti-angledly adjustable handle. Weighing 1.5kg, including built-in battery and charger for easy operation and carriage.
