Key point:
1. Aluminum shell design for industrial use
2. Highly customization option for your choice.
3. Comprehensive products line to meet different needs.
4. Meet with CE, ROHS, ISO standard.
5. One year warranty with lifelong technical support
6. 12 years China OEM factory.
Product Specification
| Display Panel | |||
| Display panel size | 15" 4:3 digital panel | ||
| Resolution | 1024*768 | ||
| Contrast | 700:1 | ||
| Brightness | 350 cd/m2 | ||
| Touch screen | Capacitive touch(Resistive/IR touch Optional) | ||
| Visual angle | 85/85/80/80 (Typ.)(CR≥10) | ||
| Computer Configuration | |||
| CPU | Intel Haswell-U 4010U,1168,1.7GHz,3M(i3,i5,i7 is optional) | ||
| Motherboard | Model:ITX-H31914T-6CD8, Intel Mini ITX Motherboard | ||
| Chipsets | Intel HM76 chipset /Intel HM65 chipset | ||
| Memory | 4GB DDR3(2GB-8GB optioanl) | ||
| Harddisk | 32GB SSD(160GB-2T HDD / 16GB-256GB SSD optioanl) | ||
| Graphics | Integrated high-definition video card | ||
| Audio | On board Realtek ALC662 sound channel high definition audio core sound card Support 5.1 channel support HD Audio support audio input and output | ||
| LAN | On board Realtek 8105E 10/100 MB network card | ||
| WIFI | 802.11n wireless network | ||
| USB | 4*USB 2.0 | ||
| Port Support | |||
| 1 x VGA port | DC connector | Power button | 1 x RS232(com) |
| 1 x WIFI connector | Others | ||
| Other Information | |||
| Color | Black/Silver/white | ||
| OS Support | Support Window XP/7/8//10/CE,Linux | ||
| Power | DC9-36V, AC100-240V | ||
| Case | entire Metal bezel / Galvanized alloy | ||
| Stander | standard VESA | ||
| Accessories | |||
| 1pcs motherboard cd drive | 1pcs touch cd drive | 1pcs touch pen | 1pcs 5A power adapter |
Products Details

Customization
As a 12 years China industrial panel PC factory, we are professional in industrial PC line, except
the high quality, timely delivery, customization is one of our main competitiveness and service we
offer to our customization. Appearance, structure, system, CPU, motherboard, memory, storage,
function, I/O port, etc, all of those can be customized as your requirement.
Except the products, we also offer you the professional solution and suggestion according to
your project.
FAQ

Q: Our important expectation that the monitor must to switch on automatically when the power go on state. It will our standard
specification for the future. Is your monitor can do this function?
A: Yes, sir. All our monitors can be built to switch on automatically when the power go on state. Just need to debug procedures.Very easy.
Q: Do you have "KCC" certifation for all your products? (approved Korean government), this mark need to sell in Korea.
A:About this certifation, we don’t have. But we have ROSH and CE funtion.
Q: Can you supply the warranty time for a longer? Such as 2 years.
A: About this question,usually, Our product's warranty is one year.and from you received the goods. If you need 2 years, we can supply, but you
need add some more money.
Q: Could you tell me about you lcd monitor, which interface does it have?
A: About these question, our monitor has VGA/DVI/ S-Vi deo interface and AV is also available, but this function need add 8$.
Q: Can the shutdown/startup delay that is in the pc control the monitor? We want to shutdown/startup both monitor and pc at the same time?
A: The shutdown/startup delay is, power management module controls the pc. We can delay shutdown/startup both monitor and pc at same time,
but monitor’s power must be supplied from pc.
Q: We have not experience importing products from China. Do you know how is the custom procedure?
A: About the custom procedure, pls don't worry.UPS or DHL are a door to door services. And they will deal all thing for you. And you just need
pay tax when you receive the goods.
