Processor

Intel® Xeon® E5-2603 v4 1.7GHz,15M Cache,6.4GT/s QPI,6C/6T (85W) Max Mem 1866MHz

Memory

4GB RDIMM, 2400MT/s, Single Rank, x8 Data Width

8GB RDIMM, 2400MT/s, Single Rank, x8 Data Width

16GB RDIMM, 2400MT/s, Dual Rank, x8 Data Width

32GB RDIMM, 2400MT/s, Dual Rank, x4 Data Width

Hard Drive

1TB 7.2K RPM SATA 6Gbps 3.5in Cabled Hard Drive

Warranty

3 Year Basic Hardware Warranty Repair, 5X10 HW-Only, 5x10 NBD On-site

Drive Bays

Up to 8 x3.5” SAS, SATA, nearline SAS,SSD drives with optional flex bay
Up to 4 x3.5” SAS, SATA, nearline SAS,SSD drives with optional flex bay
Up to 16 x 2.5” SAS, SATA, nearline SAS, SSD drives with optional flex bay

Chassis

Height:
Chassis base height - 430.3 mm (17.04")
with feet - 443.3 mm (17.45")
Width:
Chassis base width 5U - 218 mm (8.58")
with feet - 304.5 mm (11.98")
Depth:
front to rear wall (with bezel) - 558.6 mm (21.99")

Power

495W, 750W, 1100W hot-plug PSU
450W cabled PSU

RAID Controllers

Support for a maximum of 1 internal controller and one external controller
PERC Η730,PERC Η730P and PERC Η830

Chipset

Intel C610 series chipset

Storage

SAS, SATA, nearline SAS, SSD

Slots

Support for up to 2 x PCIe 2.0 + 4 x PCIe 3.0

Network Controller

2 x 1GbE LOMs

Embedded Hypervisor (Optional)

Citrix® XenServer®

Microsoft® Windows Server® 2008, with Hyper-V®

VMware® vSphere

Communications

Broadcom 5720
Optional add-in NICs
