Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer
Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer

Coconut Freeze Dried Machine / Vacuum Freeze Dryer / Lyophilizer

Share on (60776206377):


Price:$394,000.00 - $436,800.00

Quantity:


Product Overview

Description


Product Description
Working Princple of Freeze Drying Machine

Under vacuum condition, material is freeze dried via principle of sublimation. The moisture in the pre-frozen material is directly sublimed from solid state (ice) to gaseous state (vapor), without melting. Freeze dried products are formed to be sponginess, without shrinkage and excellent in rehydration, containing little water only. The freeze dried product in sealed packaging can be stored and transported at room temperature for a long time.


Advantages of Our Freeze Drying Equipment


1.Two cold traps
continuous work, continuous vapor trapping
Denmark atlas technology. continuous de-icing system(CDI system)

2. Heating plates
The material of heating plates is aviation aluminum after being anodized on the surface, releasing over 100% heat from the product by radiation. This makes heat more uniform and complete.

3.Reflection plates
The upper, lower, left, and right sides of the heating plate have reflector plates to ensure that all heat is used in the material.
Concentrate all the heat on the products, accelerate the products freeze-drying, reduce energy consumption, shorten the freeze-drying time.

4.Heating method :Double side radiation

There is a certain distance between the tray and the heating plate, not directly accepted, the product is heated evenly. good quality.


5. Automatic control system

Advanced intelligent control system keeps the system running stably and reliably in a long time. Furthermore, simple operation can be much easier to handle. So save human resources. About fully automatic display screen, We can design it according to your requirements.


6.Prodct tray

The loading capacity of the normal tray is 5KG, but the maximum loading capacity of our tray can reach 9KG, only the time of freeze-drying will be extended appropriately.


7.De-icing system

save water:The water used to melt ice comes from the products.

save energy consumption:Our equipment uses negative pressure steam melting ice, So, water is converted to steam when 15 ℃, Then melt the ice.


Freeze Dried Food

\t
Fruit
\t
Apples, pears, strawberry, blueberry, durian, banana, pineapple, papaya, starfruit, raspberry, guava, Jackfruit  lemon avocado etc.
\t
Vegetable
\t
Broccoli, mushroom, onion, noni  green beans, peas, sweet con, carrots ginger etc.
\t
Meat
\t
Pork, mutton, beef, chicken etc.
\t
Seafood
\t
Fish, shrimp, sea cucumber etc.
\t
Instant food
\t
Instant coffee, tea, Instant soup, Instant soy milk powder, milk powder Instant fruit powder etc.
\t
Powder
\t
Fruit powder, vegetable powder fruit juice powder etc.
\t
Pet food
\t
Cat food, dog food , pig food, fish food, tortoise food etc.
\t
Herbs
\t
Chinese medicines,ginseng, pioseantler, chinese wolfberry etc.
\t
Other
\t
Flower roses chocolate  ice cream yogurt  coffee bulk dates etc.

        Freeze dried strawberry                          Freeze dried mango                          Freeze dried kivi fruit

         Freeze dried green beans                         Freeze dried mushroom                      Freeze dried carrot
       Freeze dried sea cucumber                       Freeze dried beef                            Freeze dried instant soup

         Freeze dried coffee                            Freeze dried fruit powder                Freeze dried Chinese medicine

Advantages of Freeze Dried Products

1.Complete retention of nutrition

2.The shape is the same

3.The color is basically the same

4. It is easy to carry and the product after lyophilization is light in weight.

5. Suitable for long-term preservation.

Model &Specification Parameters

\t
Specification Model
\t
LG30
\t
LG50
\t
LG75
\t
LG100
\t
LG125
\t
LG200
\t
Heating Areas(m2)
\t
30
\t
50
\t
75
\t
100
\t
125
\t
200
\t
Numbers of Vapor trap
\t
Single
\t
Double
\t
Double
\t
Double
\t
Double
\t
Double
\t
Double
\t
Trapping Capacity
\t
>400kg/batch
\t
>66kg/h
\t
>110kg/h
\t
>165kg/h
\t
>220kg/h
\t
>275kg/h
\t
>440kg/h
\t
Heating Medium
\t
Water&electric
\t
Water&Steam
\t
Heating Mode
\t
Double side radiation
\t
Temperature range of Heating plates
\t
<95℃
\t
Normal Temp.~+130℃
\t
Vacuum Pressure (Pa)
\t
20~133
\t
Need Refrigeration Capacity (t0=-40℃,tk=-35℃) (Kw)
\t
55
\t
80
\t
120
\t
160
\t
200
\t
320
\t
Consumption of Steam(kg/h)
\t
None
\t
150
\t
200
\t
280
\t
340
\t
400
\t
690
\t
Electric Power Supply
\t
75KW
\t
40KW
\t
43KW
\t
63KW
\t
69KW
\t
85KW
\t
115KW
\t
Tray Numbers
\t
78
\t
80
\t
120
\t
180
\t
240
\t
300
\t
480
\t
Loading Capacity of Raw Material(KG)
\t
>390
\t
>400
\t
>600
\t
>900
\t
>1200
\t
>1500
\t
>2400
Detailed Image
Packing & Delivery
Service & Warranty

Service:
1. When the buyer buys our equipment, we will send professional engineers to guide the installation and commissioning of the equipment to ensure the safe and efficient operation of the equipment.


2. Professional mechanical engineers will provide theoretical knowledge to the staff of the buyer.


3. When the staff of the buyer has mastered the theoretical knowledge of mechanical equipment, the engineer will direct and carry out the practical operation.Ensure the combination of theoretical knowledge and practice.Make the equipment efficient and energy efficient.

Warranty
1. We guarantee that the commodity hereof is made of the best materials and new brand with top workmanship, and in accordance with quality specification stipulated in product Contract and Appendix.


2. Guarantee period shall be within 12 months from the date of acceptance. During this period, if there are quality problems, we will provide solution by verbal or written communication. If the problem is unsolved, our engineers will repair for you on site as soon as possible.


3. The buyer will provide the maintenance plan if the buyer has the operation fault causing the mechanical failure.If the buyer cannot repair itself, the buyer will send a professional engineer to the site for guidance, but the cost will be borne by the buyer.

Certifications
Exhibition Overseas
Company & Work Shop

Shenyang Aerospace Xinyang Quick freezing Equip. Manuf. Co., Ltd was founded in 1985, a leading enterprise incorporating the research, manufacturing, sales and services of food processing equipment and freezing technology. Freeze drying equipment and IQF freezing equipment are widely used around the world.

Xinyang Company closely cooperated with Atlas Company in Denmark, Harbin Commerce University, Zhejiang University and Northeastern University, etc., our team have supported over 1,500 food engineering projects both domestically and abroad, our products have been exported to USA, Canada, Germany, Netherland, Singapore, Thailand, Malaysia, Indonesia, Korea, Myanmar, Chile, Nigeria etc.

Over 30 years’ experience make us expertise in the food processing equipment manufacture, and we’re confidence to provide you with high quality products and also good services.
