Sini Hot Sell Middle Speed Automatic Paper Plate Bowl Forming Lunch Box Make Machine In India
- Category: >>>
- Supplier: Zhejiang Sini Machinery Co. Ltd.
Share on (60776353571):
Product Overview
Description
Products Description
JBZ-D30 Paper
Bowl Forming Machine
Bowl Forming Machine
JBZ- D30 Paper Bowl Forming Machine is developed on the base of absorbingKorean newest paper bowl machine, It makes big size paper bowl, such as soupbowl, fast noodle bowl etc. The procedure as follows: Automatic paper feeding,two step pre-heating, sealing, top mouth lubrication, bottom Punching, twotimes of bottom heating, bottom knurling, top mouth curling and bowl stackwith photo-cell detection, fault alarm and counter.
Model | JBZ-D30 | JBZ-DZ | |||||
Bowl size | 20-50 oz | Uni-president 1100,980 master kong 998,460 etc. | |||||
Raw material | One side PE coated paper | ||||||
Height | 50-110mm | 35-70 | |||||
Top mouth diameter | 90-140 | 50-120 | |||||
Bottom diameter | 70-110 | 40-95 | |||||
Bottom depth | ≤6~12 | ≤6~12 | |||||
Angle | 3-8.5° | 2-8° | |||||
Capacity | 30~40 pcs/min | ||||||
Power source | 380v 50Hz(it can be changed if customer require) | ||||||
Total power | 13kw | ||||||
Weight | 2300kg | ||||||
Package Size(LxWxH) | 3150x1580x1850mm 800x750x1300mm | ||||||
Remark | The machine be with ultrasonic can produce two side PE coated paper | ||||||
Air source | 0.2m^3/min 0.6MPa customer-owned | ||||||
1. Increase the output. On the basis of the same power 6kw, it speeds up to 55-60pcs/min from
35-45pcs/min before.
2. The bottom paper is sent by stepper motor,which controls the interval of bottom papers about
0.1mm, so that the machine is more paper saving and performs more stably.
3. The inner structure adopts the vertical axis gear drive system to avoid chain loosening and
malposition problems.
4. Automatic lubrication system,which reduces the friction of machine parts and improves the
machine maintenance, works a lot.
5. The machine is equipped with optically controlled non contact switch.
6. Paper feeding working station is driven by cams without noise,performing stably and well,
which is pioneer technology at home.
7. The machine adopts the gear motor in replacement of the separate reduction box and motor
,making the drive system simpler and more stable.
35-45pcs/min before.
2. The bottom paper is sent by stepper motor,which controls the interval of bottom papers about
0.1mm, so that the machine is more paper saving and performs more stably.
3. The inner structure adopts the vertical axis gear drive system to avoid chain loosening and
malposition problems.
4. Automatic lubrication system,which reduces the friction of machine parts and improves the
machine maintenance, works a lot.
5. The machine is equipped with optically controlled non contact switch.
6. Paper feeding working station is driven by cams without noise,performing stably and well,
which is pioneer technology at home.
7. The machine adopts the gear motor in replacement of the separate reduction box and motor
,making the drive system simpler and more stable.
More products
Application
About us
FAQ
1.What can your machine do?
Produce paper cup, paper bowl, ice cream cone, paper plate, and other paper containers with different
machines.
2.What size of the cup/bowl you can make?
depends on machine models, can make minimum 2oz to maximum 22oz cup, 20 to 50oz bowl and
other different sizes according to customer's requirements.
3.Are you a manufacturer?
Yes,We produce paper cup machine since 1998.
4.what about the payment term ?
We accept TT, LC and cash.
5.What information should I offer if I want to get a quotaion?
- Speed requirement
- Cup size(top diameter,bottom diameter,and height), better offer with cup sample
- Paper thickness
- Use plastic lid or not
- Cup size(top diameter,bottom diameter,and height), better offer with cup sample
- Paper thickness
- Use plastic lid or not
6.what’s your advantages ?
- We produce paper cup machine since 1998, ver professional manufacturer for 20 years.
- We have customer all over the world.
- We have CE certification and ISO certification.
- We have professional after-sale team which can response immediately.
- We have customer all over the world.
- We have CE certification and ISO certification.
- We have professional after-sale team which can response immediately.
