Disposable Plastic Jelly Milk Cup Making Machine Price
- Category: >>>
- Supplier: Ruian Litai Machinery Co. Ltd.
Share on (60776365034):
Product Overview
Description
*Pictures and related technical parameters of products will be updated continuously without prior notice.The right of final interpretation of this information belongs to our company.
Product Paramenters
Technical Parameters | ||||
Model | TQC-750 | TQC-650B | ||
Max. Forming Area | 750*480mm | 650*320mm | ||
Max. Forming Depth | 125-180mm（custom height） | |||
Sheet Thickness | 0.3-1.8mm | |||
Sheet Width | 760mm | 650mm | ||
Max. Forming Speed | 30 times/min | |||
Air Pressure | 0.6-0.8mpa | |||
Air Consumption | 3.0m³/min | 2.0m³/min | ||
Water Consumption | 0.7m³/h | 0.5m³/h | ||
Rated Power | 140Kw | 98Kw | ||
Used Power | 98Kw | 72Kw | ||
Power Supply | AC 380V,50Hz, Three-phase, Four-wire | |||
Dimension | L8500*W2200*H3200mm | L7000*W2000*H3100mm | ||
Weight | About 6.5T | About 5T | ||
MACHINE MAIN PARTS | ||
Touch Screen/PLC | SIEMENS (Germany) | |
Servo Motor | YASKAWA (Japan) | |
AC Contactor/Circuit Breaker | SCHNEIDER (France) | |
Proximity Switch | ROCKWELL (USA) | |
Solenoid Directional Valve/solenoid overflowing valve/counterbalance valve | YUKEN (Taiwan) | |
Intermediate relay | IDEC (Japan) | |
Intermediate relay base | OMRON (Japan) | |
Forming Valve | CKD (Japan) | |
Solenoid Valve | SMC (Japan) / Mindman (Taiwan) | |
Products Description
APPLICATION
Plastic cup thermoforming machine is our lasted developed product, Sheet feeding and stretching part are driven by servo
motor.Machine produces disposable products, such as plastic cup, bowl, lid, and box through the workflow of sheet feeding, sheet heating, forming, cutting and blowing, widely used and suitable for most of the customer requested. PLC for program, manual interface for operation, stable, low noise, and high efficiency.
motor.Machine produces disposable products, such as plastic cup, bowl, lid, and box through the workflow of sheet feeding, sheet heating, forming, cutting and blowing, widely used and suitable for most of the customer requested. PLC for program, manual interface for operation, stable, low noise, and high efficiency.
Main Function
1.positive and negative pressure forming device.
2.vacuum forming device.
3.touch screen computer temperature module point to point control function.
4.air control device.
5.cooling device.
6.die, mold temperature control function.
7.automatic punching and cutting function.
8.automatic stack counting function.
9.edge automatic rewinding function.
10.safety protection device.
3.touch screen computer temperature module point to point control function.
4.air control device.
5.cooling device.
6.die, mold temperature control function.
7.automatic punching and cutting function.
8.automatic stack counting function.
9.edge automatic rewinding function.
10.safety protection device.
SUMMARY OF MACHINE
1.Industrial manual interface and PLC of SIEMENS (Germany) make the high degree automation, accurate control and convenient operation. The document storage function simplifies the operational processes.
2.Working stations is driven by stable four guiding-pillars (GCr15 steel, outside is hard chrome plated) structure. Wear
resistant, and extend equipment life.
resistant, and extend equipment life.
3.Stretching servomotor of YASKAWA (Japan) controls the speed of the upper and lower die, this can maintain the uniform strength to ensure that the bottom thickness of each cup is uniformly. And the servo motor also controls precisely sheet feeding to avoid wasting.
4.Hydraulic driven system can provide adequately movement speed and strongly punching power.
5.The whole part is driven by hydraulic system, which is reliable and steady. Using proximity switch of ROCKWELL (USA) leads to excellent mould positioning precision.
6.The heater added vacuum insulation cotton, which shows quick response rate, short processing time, and save energy.
7.Sharp chain uses 65#Mn, which has higher strength, better heat resistance and elasticity than 45# steel.
8.The electric lubricating oil pump can automatically inject lubricating oil regularly and quantitatively through the control of computer under the condition of unmanned control, which can make the rotating part of the machine get proper and reasonable lubrication.
9.Sheet feeding servo motor adopt YASKAWA brand, made in Japan, the rated power is 3Kw, ensure stable operation in the process of feeding.
1. Fully servo driven machine.no noise.no vibration,thermoforming good and fast.
2. Fully machine in compact structure,taking small floor space.
3. Can be adapted to a variety of materials,and the products thicker 8% than the average machine products.
4. Furnaces automatic removal device, can be turned down at any time during production without breaking the sheet reaching without wasting materials.
5. Electric furnace temperature control system uses intelligent automatic compensation control,a control,a control of a
regulator,easy to adjust the temperature uniformity,easy to use,simple,fast heating,low temperature three times up and down the oven roast slices.
6. Forming,cutting die servo-driven,two-way adjustable for upper and lower mold stroke,in which the upper mold electric adjustable in clamping direction. The upper and bwer molds height position can be adjusted conveniently and fast under the clamping state;lower mold in clamping direction readily accessible buffer,increasing the clamping speed,avoiding shock.
7. Auto cutting, auto counting,auto transmission by PLC.
8. Labor saving, only 1-2 workers packing.
3. Can be adapted to a variety of materials,and the products thicker 8% than the average machine products.
4. Furnaces automatic removal device, can be turned down at any time during production without breaking the sheet reaching without wasting materials.
5. Electric furnace temperature control system uses intelligent automatic compensation control,a control,a control of a
regulator,easy to adjust the temperature uniformity,easy to use,simple,fast heating,low temperature three times up and down the oven roast slices.
6. Forming,cutting die servo-driven,two-way adjustable for upper and lower mold stroke,in which the upper mold electric adjustable in clamping direction. The upper and bwer molds height position can be adjusted conveniently and fast under the clamping state;lower mold in clamping direction readily accessible buffer,increasing the clamping speed,avoiding shock.
7. Auto cutting, auto counting,auto transmission by PLC.
8. Labor saving, only 1-2 workers packing.
Contact Us
Facebook
https://pse.is/3urql5
LinkedIn
https://pse.is/3ythvl
YouTube
https://pse.is/3zkhvj
Instagram
https://pse.is/3yhe6m
Pinterest
https://pse.is/3vd57m
Tiwtter
https://pse.is/3z675l
Official website
//www.litai.cc/
Tik Tok
//pesc.pw/478rpe
Made in China
https://pse.is/3rh2nv
Company Profile
Exhibition & Customers
Long-term Cooperation Brand
Packaging Shipping
FAQ
Q1: Are you a factory or trading company?
A1: We are a factory, and we export our machines to more than 80 countries since 2001.
Q2: How long is the warranty period?
A2: We have a professional QC department in charge of products' quality.
Q3: How long is the warranty period?
A3: 13months calculated from the date of shipment from our factory.During warranty period, except the artificial factor, the spares are free to maintenance, beyond the warranty time, the buyer needs to pay the spare charge and shipping cost.
Q4: How to install the machine?
A4: We will send technician to your factory to install the machine, and teach your workers to use it. You pay all related costs, including visa charge, double-way tickets, hotel, meals, and technician salary.
A1: We are a factory, and we export our machines to more than 80 countries since 2001.
Q2: How long is the warranty period?
A2: We have a professional QC department in charge of products' quality.
Q3: How long is the warranty period?
A3: 13months calculated from the date of shipment from our factory.During warranty period, except the artificial factor, the spares are free to maintenance, beyond the warranty time, the buyer needs to pay the spare charge and shipping cost.
Q4: How to install the machine?
A4: We will send technician to your factory to install the machine, and teach your workers to use it. You pay all related costs, including visa charge, double-way tickets, hotel, meals, and technician salary.
