Hot sales Denison 3D03,4D03,3D06,4D06 electro hydraulic directional valve,pilot operated hydraulic control valve

Product Overview

Description

Hot sales Denison 3D03,4D03,3D06,4D06 electro hydraulic directional valve,pilot operated hydraulic control valve

1. Completely interchangeable with original

2. Directional control valve solenoid or hydraulically controlled

3. Extremely low pressure drop – energy saving

4. High functional limit up to 300 l/min at nominal pressure

5. Nominal operating pressure 350 bar

6. Wide variety of spool types available

7. Permissible pressure in the tank port up to 350 bar with external drain, up to 210 bar with internal drain (see characteristics)

8. Coils are easily replaced without any oil leakage

9. Interchangeability of spools and bodies due to high precision manufacturing processes

10. Mounting configuration conform to ISO 4401

11. Every valve is factory tested prior to delivery

12. 1 year of warranty

13. Short delivery time



 Some models for your reference:

4D01-3203-0302-C1G0M	4D01-3208-0302-C1G0M	4D01-3202-0302-C1G0M	4D01-3246-0302-C1G0M	4D01-3201-0302-C1G0M
4D01-3208-0302-C1G0M-52	4D01-3751-0902-C1G0M	4D01-3207-0302-C1G0M	4D01-3108-0501-C1G0M	4D01-3108-0601-C1G0M
4D01-3111-0101-C1G0M	4D01-3151-0101-C1G0M	4D03-3407-0705-50B5	4D03-3407-0705-60B5	4D01-3111-0101-C1G0Q-V9W1
4D01-3151-0101-C1G0Q	4D06-3403-0304-60B1	4D06-3414-0304-60B1	4D06-3403-0304-50B5	4D06-3408-0304-50B1
4D06-3408-0304-50B5	4D01-3151-0201-C1G0M	4D02-3151-0101-D1G0L	4D02-3151-0201-D1G0L	4D01-320T-0302-C1G0M
4D01-3751-0902-C1G0M-K6	4D02-VB07-0303-44B1G0Q-10	4D03-3B08-0303-10C1G0M-E	4D06-3ABB-0103-30C1G0Q-U2K6	4D03-3C03-0403-10C1GOQ
4D03-3C03-0403-20C1G0Q-H	4D03-3C08-0403-20C1G0Q-H	4D03-3C03-0403-10C1W30	4D03-3C03-0403-10C5GOQ	4D03-3C03-0403-20C1W30-B



 Technical Specifications:
