Product Overview
Description
Dear Sir or Madam
Because the products are customized products, the products are different in size, voltage and power, so the price is different. Please contact us before ordering. We will give you a favorable price according to the specifications of the products.
Customized Size / Voltage / Watt / Shape
Oil-Drum silicone rubber heater specification
Oil Drum | Size | Voltage | Power | Gross Weight | Temperature controller |
200L | 250*1740mm | 220V | 2000W | 1.6kgs | 30-150℃ Switch temperature controller Or Digital show temperature controller |
200L | 125*1740mm | 220V | 1000W | 1.1kgs | |
20L | 200*860mm | 220V | 800W | 0.9kgs | |
20L | 120*860mm | 220V | 500W | 0.7kgs |
LDB Flexible heating plate
Model | Size | Power |
LDB-A | 610*305mm | 600W |
LDB-B | 610*610mm | 1200W |
LDB-C | 1220*610mm | 2400W |
Ammonia Gas bottle heating plate
Model | Size | Heating area | Voltage | Power | Thermocouple | Temperature switch |
47L | 1100*690mm | 1000*600mm | 220v | 3000w | K type 2pcs | 2Pcs |
470L | 1600*800mm | 1400*700mm | 220v | 4000w | K type 3pcs | 3Pcs |
930L | 2000*1000mm | 1600*900mm | 220v | 6000w | K type 3pcs | 3Pcs |
All the above specification only for reference,the products can be made as customers’ designs,shapes and power.
Maximum temperature resistant of insulate | 300℃
|
Maximum operating temperature
| 250℃-300℃ |
Withstanding voltage
| 1500V/5s
|
Power Tolerance
| ±8%
|
Electric voltage
| >5KV
|
Max Width
| 1170mm
|
Thickness
| 1.5mm (Min:0.8mm,Max:4mm)
|
Lead wire
| 25cm (as requirements)
|
3M Glue | As requirements |
Main applications:
1) Thermal transfer equipment
2) Freeze or condensation prevention in housings containing electronic equipment, for examples: traffic signal boxes, automatic teller machines, temperature control panels, gas or liquid control valve housings
3) Drums and other vessels and viscosity control and asphalt storage
4) Medical equipment such as blood analyzers, medical respirators, test tube heaters, etc.
5) Computer peripherals such as laser printers, duplicating machines
Click below "Send" pls,best price is ready for you!
