Industrial Stainless Steel Metal Waterproof USB Keyboard with Trackball Touch Screen

Electrical Data

Supply Voltage

5.0V DC

Current Rating

Appr. 30mA

EMC Standard

It is compliance with the council EMC directive 2004/108/EC

EN55022

2006+A2:2010

EN55024

1998+A1:2001+A2:2003

Lifespan

>5 years

SPECIFICATION:

Number of Keys: custom

Material: stainless steel (front panel) and alumina alloy (scaleboard)

 Key travel:0.4mm

keyswitch lifespan: more than 10 million of operations

Dimensions:  92x 76.5 x2.0mm

Supply Voltage: +5V DC +/-5%

Communication interface: USB or PS2 (optional)

 Protection Level: IP65(front panel)

Operating temperature:-40 ~+70

Storage temperature: -50 ~ +80

MECHANICAL DATA

·Different size available:392x110mm,400x124mm,431x126mm

·Key top style: Protuberant rectangular keys.

·Key travel: 2.0mm

·Switch life: more than 10 million of operations.

·Lettering:  laser-etched or high quality ink print.

·Actuator/keys materials: polymer

ELECTRICAL DATA

·Supply Voltage: +5V DC +/-5%

·Current Rating: appr. 30mA

·EMC Standard: It is compliance with the council EMC directive 89/336/EEC EN55022:1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003

·Emission: EN 50081-1

·Immunity: EN 50082-1

·Lifespan>5 years

·Switch Contact Material: Carbon-on-Gold key switch technology PCB.

·Interface: PS2, USB available.

·OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/win7/win8/win9/win10, Linux, Unix, Mac OSX

ENVIRONMENTAL ADAPTABILITY

·Operating temperature:-20oC to +60oC

·Storage temperature: -30oC to +70oC

·Operating RH: 30-90%

·Atmospheric pressure: 60-106Kpa.

·Saline mist: 96 hours, IEC 60512-6

·Damp heat test at + 40oC: 21 days, IEC 60512-6

·Dry heat test at + 85oC: 10 days, IEC 60512-6

RELIABILITY

·RoHS Compliant, CE and FCC,ESD

·Protection Level: IP65(front panel)

·Vandal resistant IK10

·Key Lifespan >10 million actuations

·MTBF >50000H

·MTTR <30min
