Automatic PLC control 3d drum powder mixer for coffee flour spices seeds color herb powder mixing machine
- Category: >>>
- Supplier: Jiangyin Jirui Machinery Manufacturing Co. Ltd.
Share on (60779251975):
Product Overview
Description
Hurry Enquiry us!!!
3 Dimensions Powder Mixer
for
Pharmacy Food and Chemical Industry
SYH50L-SYH1000L
20-400kg/batch
Product Description
Application
Applications
The three-dimensional mixer is widely used in pharmaceutical, chemical, food and other industries. It can mix powder or granular materials with good fluidity evenly, so that the mixed materials can reach the best mixing state.
Principle
Working Principle
When it works, the mixer is provided with three-dimensional movement, and carries out revolution and rotation. The mixer has powerful turbulent action to accelerate material flowing and dispersing and makes turning and translational movement to conquer the impact of centrifugal force, so that gravity segregation and agglomeration will not occur in the materials, there is no dead corner, and even mixing is ensured.
Features
Features
1). Uniformity: 99.9%
2). The effective loading rate of the container: 80%
3). The machine height is short
4). Partition wall installation can be realized
5). Stepless speed regulation can be achieved
6). Long life and low noise
7). High mixing efficiency
8). Vacuum feeding and lifting machine feeding are available.
Structure
More details
Feeding method (optional)
1. Manual feeding 2. Vacuum feeding 3. Lifter feeding
 |
 |
 |
Vacuum feeding device(optional)
Technical parameter
| Spec. |
Total Volume (L) |
Working Capacity (L) |
Mixing Capacity (KG) |
Power (Kw) |
Rotating Speed (rpm) |
Weight (KG) |
| SYH-50 | 50 | 40 | 20 | 1.1 | 2-12 |
150 |
| SYH-100 | 100 | 80 | 40 | 1.5 | 2-12 | 220 |
| SYH-200 | 200 | 160 | 80 | 2.2 | 2-8 | 400 |
| SYH-400 | 400 | 320 | 160 | 4 | 2-8 |
500 |
| SYH-500 | 500 | 400 | 200 | 5.5 | 2-8 | 750 |
| SYH-600 | 600 | 480 | 240 | 5.5 | 2-8 | 900 |
| SYH-800 | 800 | 640 | 320 | 7.5 | 2-8 | 1100 |
| SYH-1000 | 1000 | 800 | 400 | 7.5 | 2-8 |
1200 |
Services
Packaging & Shipping
We have long-term working shipping forwarder. We can do our best to send machine to your port safe and sound.
If you need, we can help you do custom clearance.
Packaging Details: 1. Outside package: Standard export wooden cases.
2. Inner package: Air bubble film and stretch film.
Delivery Details: about 40 workdays after payment.
