tpms for passenger car or light trucks tire pressure tpms internal sensor

Product Overview

Description

tpms for passenger car or light trucks tire pressure tpms internal sensor









1. What are the advantages of TPMS ?



Reduce Driving Risks



Improve Fuel Economy



Prolong lifetime of the tires



2. Features:



Monitor Features:



Reliable and easy to install.
Fixed high/low pressure warnings.
Fixed high temperature warnings.
Visible and audible alerts.
Selectable pressure units: PSI or BAR.
Selectable temperature units: C or F .
Monitors up to 5 tires maximum.
Displays pressure or temperature of 4 tires simultaneously.





3. Specifications:



Monitor specifications:



Operating voltage:	12 to 24V
Frequency	433.92MHz
Operating temperature	-40 to +80° C
Size	96x 59x 27mm
Weight	42g



External Sensor Specifications:



Pressure range:	0 to 6 bar, 0 to 87psi
Pressure sensitivity:	± 0.1 bar or 1.5psi
Temperature sensitivity:	± 3℃
Transmission power:	< 10dBm
Transmission frequency:	433.92MHz
Battery life:	1 years (Sensor battery replaceable)
Operating temperature:	-20 to +85° C
Weight:	6 grams
Size:	diameter:18mm, height:13 mm



4. Our Facilities:





5. Our Certificates (CE, E-mark, FCC, RoHS, ISO9001) & Patent





6. Cooperate with us, you will gain:



0EM or ODM service



Professional Research & Development Engineer



Competitive Price & Professional sales team



2-4 weeks leadtime

Looking Forward to Cooperating with You!
