backpack portable core drill rig hand held concrete core drill rig rock core drilling machine for sale

Product Overview

Description

1.A brief introduction of the BXZ-2L vertical backpack drill rig

BXZ-2L Vertical knapsack Core rig is a removable backpack portable coring rig, mainly used in mineral exploration, geochemical exploration, shallow sampling, vein exploration, geoscience research, geotechnical engineering, engineering investigation, oil field exploration. Water conservancy engineering survey, highway engineering survey,Tunnel lining, inverted arch detection.

The main features of BXZ-2L vertical backpack core drilling machine are compact structure, detachable, small volume, light weight, easy to carry; imported brand gasoline engine with large horsepower and guaranteed drilling depth; with drilling frame, field operation is more convenient and safe.

2. Technical parameters of Type BXZ-2L Vertical backpack drill rig

Project	Parameter
Power brand	Coler
motive power	7.75HP
Fuel tank volume	1400ml
driving mode	gear drive
starting mode	Pull rope start
Clutch mode	Automatic clutch
Core mode	rotary
End hole speed	540r/min
gear ratio	7:1
driving mode	infinitely variable speeds
Drill pipe size	32*800mm
Drill pipe size	30m
aperture	32~120mm
Mainframe net weight	52kg
Mainframe net weight	550*450*420mm
packing measurement	1050*600*550mm

3.The packing list of BXZ-2L vertical backpack drill rig

Project name	Specification	Unit	Number
Drill rig (including drill rig)	BXZ-2L	set	1
Drill rod (including a male parent)	Φ32*800	root	38
Head	Φ46	pcs	1
Core tube	Φ46*700	root	1
Alloy bit	Φ46	pcs	1
Diamond bit	Φ46	pcs	1
Head	Φ60	pcs	1
Core pipe	Φ60*700	root	1
Alloy bit	Φ60	pcs	1
Diamond bit	Φ60	pcs	1
Gasoline high pressure pump		set	1
Water suction pipe	Φ20*1000	root	1
Water absorbing filter		pcs	1
Backwater pipe	Φ13*1000	root	1
supply pipe	Φ13*4500	root	1
