Flexible Polyurethane Tube PU Spring Coil Hose Pneumatic Colorful Spiral Hose
- Category: >>>
- Supplier: Hengshui Yatai Especial Rubber Products Co. Ltd.
Share on (60780426506):
Product Overview
Description
Flexible Polyurethane Tube PU Spring Coil Hose Pneumatic Colorful Spiral Hose
Medium pressure hydraulic applications, hoisting, hydraulic transmission.
Mineral and biological oils, ASTM 1, ASTM 3, polyglycol based oils, water, water oil emulsions.
HOSE MARKING:YATAI HYDRAULIC HOSE SAE 100 R7/R8 3/4″(DN19) W.P 140BAR 2030PSI
| YATAI PART.REF. | HOSE I.D | R.O.D | O.D | MAX W.P | MIN B.P | MIN B.R | W.T | ||||
| DN | Dash | inch | mm | mm | bar | psi | bar | psi | mm | kg/m | |
| TB R7 3 | 3 | -1 | 1/8" | - | 8.5 | 172 | 2500 | 689 | 10000 | 13 | 0.04 |
| TB R7 5 | 5 | -3 | 3/16" | - | 10.8 | 210 | 3040 | 840 | 12180 | 20 | 0.07 |
| TB R7 6 | 6 | -4 | 1/4" | - | 13.0 | 207 | 3000 | 827 | 12000 | 33 | 0.09 |
| TB R7 8 | 8 | -5 | 5/16" | - | 15.1 | 172 | 25000 | 689 | 100000 | 46 | 0.10 |
| TB R7 10 | 10 | -6 | 3/8" | - | 17.0 | 155 | 2250 | 621 | 9000 | 51 | 0.14 |
| TB R7 13 | 13 | -8 | 1/2" | - | 20.7 | 140 | 2030 | 560 | 8120 | 76 | 0.21 |
| TB R7 16 | 16 | -10 | 5/8" | - | 22.0 | 110 | 2000 | 440 | 8000 | 10 | 0.21 |
| TB R7 19 | 19 | -12 | 3/4" | - | 26.0 | 86 | 1250 | 345 | 5000 | 127 | 0.29 |
| TB R7 25 | 25 | -16 | 1" | - | 32.0 | 69 | 1000 | 276 | 4000 | 203 | 0.54 |
| TB R8 5 | 5 | -3 | 3/16" | - | 13.1 | 345 | 5000 | 1400 | 20000 | 38 | 0.12 |
| TB R8 6 | 6 | -4 | 1/4" | - | 13.1 | 345 | 5000 | 1400 | 20000 | 51 | 0.18 |
| TB R8 8 | 8 | -5 | 5/16" | - | 17.0 | 300 | 4350 | 1200 | 17400 | 60 | 0.20 |
| TB R8 10 | 10 | -6 | 3/8" | - | 19.4 | 276 | 4000 | 110 | 16000 | 64 | 0.22 |
| TB R8 13 | 13 | -8 | 1/2" | - | 22.7 | 241 | 3000 | 965 | 14000 | 102 | 0.31 |
| TB R8 16 | 16 | -10 | 5/8" | - | 25.0 | 130 | 1900 | 520 | 7600 | 140 | 0.34 |
| TB R8 19 | 19 | -12 | 3/4" | - | 29.0 | 110 | 1600 | 440 | 6400 | 170 | 0.37 |
| TB R8 25 | 25 | -16 | 1" | - | 34.0 | 80 | 1200 | 400 | 4800 | 230 | 0.48 |
CONTINUOUS SERVICE TEMPERATURE RANGE: -40°F / +212°F; -40°C / +100°C
INSERT:SHF TYPE
TUBE:OIL RESISTANT THERMOPLASTIC ELASTOMER
REINFORCEMENT:ONE POLYESTER BRAIDS
COVER:THERMOPLASTIC ELASTOMER WITH HIGH OZONE AND ABRASION RESISTANCE
MAX OPERATING TEMPERATURE: 212°F 100°C FOR OIL,149°F 65°C FOR AIR, WATER AND WATER BASED FLUIDS
APPLICABLE SPECS: EN 855 R7, SAE 100R7
