JSZ7 Trinocular Contrast Zoom Stereo microscope with digital camera
- Category: >>>
- Supplier: Jinan,Chenda,Testing,Machine,Manufacturing,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
JSZ7 Trinocular Contrast Zoom Stereo microscope with digital camera
Technical features:
1. Achromatic objective lens and wide field, high eye point eyepiece combination, make the field
wide, flat and clear.
2. Precision zoom rotation ensure continuous zoom.
3. Long working distance objectives, endoscopic operation is extremely easy.
4. Binocular observation can be synchronized with photography, camera shooting.
5. With anti-static function, protect sensitive components from electrostatic damage.
6. Optional 0.5X, 1.5X, 2X large objective lens.
Technical Parameter
Model | Name | REMARK |
Objective Lens | 0.7×-4.5×； WD=110㎜ | |
ES10 | 10× Large Field Of Vision Flat-field Eyepiece | FN=20㎜ |
ES15 | 15× Large Field Of Vision Flat-field Eyepiece | FN=16㎜ |
ES20 | 20× Large Field Of Vision Flat-field Eyepiece | FN=13mm (Original Olympus Eyepiece) |
ES25 | 25×Flat-field Eyepiece | FN=9㎜ |
ES30 | 30×Flat-field Eyepiece | FN=7㎜ |
18T.4 | 0.5×Camera Eyepiece | WD=192㎜ |
18T | Binocular Body | Tilt 30° |
18TA | Trinocular Body | Tilt 30° |
Loading Plate 1 | Black And White Plastic(φ95) | |
Loading Plate 2 | Frosted Glass(φ95) | |
Oblique Spot Light | Kodak Halogen | |
Transmittance Light | Kodak Halogen | |
Annular Fluorescent Lamps | External Hanging Type | |
LED Annular Lights | External Hanging Type | |
RZ300 | Digital Cameras | USB2.0 Data Interface. 3 Million Real-time Pixel. With Software. |
Computer | ||
printer |
Packing & Delivery
1> Inner package: dust-proof plastic bag
2> Outer package: standard export wooden case with pallet
3> Special package: according to buyer's requirements
4> The packages suitable for international transport by sea, by air or any other delivery methods
Shipping
Suitable for international transport through shipping by sea, by air or any other delivery method.
Our Factory
Jinan Chenda Testing Machine Manufacturing Co.,ltd
Jinan Chenda Testing Machine Manufacturing Co., Ltd. was established in 2003, and is a professional comprehensive company which integrates research and development, production, marketing and service. Our products are applied widely in many fields such as scientific institutions, colleges, metallurgical, construction materials, railway trains, highway traffic, rubber plastic, wire and cable, and fire facilities.
Our company is located in the beautiful spring city - Jinan, which is the center for developing testing machines in China as well as the largest testing machines producing base at home.
We are specialized in providing:
1. Hydraulic universal testing machines
2. Electronic universal testing machines
3. Friction and wear testing machines
4. Complete impact testing equipment and bending testing machines
Customer From Russian Come to visit our factory
Customer From Canada come to visit our factory
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-7 days if the machine is standard are in stock. or it is 15-20 days if the machine is special are not in stock, it is according to specification.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
B: Payment by Alibaba Trade Assurance.
We are a member of Alibaba Trade Assurance which is a new service provided by Alibaba, safeguarding buyer's payment to suppliers to ensure suppliers fulfill their obligations regarding order delivery and product quality.
If you have another question, pls feel free to contact us as below:.
