T50 PN16 DN15-DN40 Multi jet dry type Cast Iron External adjustment water meter





Dry dial water meter(LXSG-15-50)





Brief introduction:


The intelligent digital water meter is mainly composed of a meter case, a cover, a counting mechanism, a measuring mechanism, etc. The counting mechanism and impeller are completely isolated by magnetic transmission, and the reading part of the wheel is dry and keeps the reading part clear for a long time by using water.Anti-fog, anti-fouling and other characteristics.





Characteristic:


High accuracy, accurate measurement, convenient maintenance, technical index up to GB/T778.1~3-2007 standard, dry counter and measured water can keep the indication clear for a long time, and water contact parts are made of high quality anti-corrosion and anti-fouling material to make standard pipe thread.Can be installed with wireless and wired remote transmission function, the realization of remote meter reading intelligent metering terminal.





Working condition(s):


Water temperature 0.1~50℃, working pressure≤1.6MPa.





Figurative diagram:

















Shape dimension & weight:


















































































Diameter


(DN)



Length


(mm)



Width


(mm)



Height(mm)



Connection thread



Weight


(Kg)



L



L1



B



H



d



D



15



259



165



96



106



R1/2



G3/4 B



1.26



20



294



190



96



107



R3/4



G1 B



1.5



25



382



225



101



114



R1



G1 1/4 B



2.48



32



385



230



101



114



R1 1/4



G1 1/2 B



2.81



40



430



300



















4.89



50



446



300



















5.94









Allowable error of indication & error Curve:


From Q1 inclusive up to but excluding Q2 is ± 5%;
From Q2 inclusive up to and including Q4 is ± 2% for T30 and ± 3% for T50 ;
