150 Mbps WiFi Module ralink MT7601U Chipset USB WiFi Wireless Adapter
Product Description
Product Description of MT7601U WiFi Module
* KWH-7601-U3 is designed base on MT7601U chipset.
* It is a highly integrated single-band (2.4GHz) IEEE 802.11n 1X1 System-on-Chip (SoC), specifically designed to support High Throughput data rates for next generation WLAN products.
* It supports IEEE802.11i safety protocol, along with IEEE 802.11e standard service quality.
* It supports the new data encryption on 64/128 bit WEP and safety mechanism on WPA-PSK/WPA2-PSK, WPA/WPA2.
* It can implement the wireless network function on the laptop/desktop/MID and other wireless devices easily .
Specification
| Description | Cheap OEM 150 Mbps module ralink rt7601 chipset usb wireless adapter |
| Product name | WiFi Module |
| Item/Part number | MT7601U |
| Dimensionis( L x W mm) | 17.4(L) x 13.1(W) x 0.6(H) mm |
| Main IC | MT7601U |
| Operation Voltage (V) | 3.3V |
| Host Interface | USB 1.1, USB 2.0 |
| Operating temperature | -10 ℃ to +70 ℃ |
| Storage temperature | -40 ℃ to +125 ℃ |
| Data rate | 150 Mbps |
| RF Chains | 1T1R |
| Working mode | Infrastructure, Ad-Hoc |
| Antenna Type | Optional |
| Frequency Range | 2.40GHz~2.4835GHz |
| Standard | IEEE802.11B/G/N, CSMA/CA, ACK |
| Modulation type | OFDM/DBPSK/DQPSK/CCK |
| The transmit distance | Indoor<100M, Outdoor<300M |
| Warranty | 12 Months |
| Samples | Available |
| Feature | 1. Intelligent control of household appliances is controlled by APP |
| 2. Can customized APP and hardware | |
| 3. The grade of SOC chip can realize multi-IOT and multi-channel of control function | |
| 4. Low poer sonsumption is good for mobile devices | |
| 5. With smart connection of remote control, easy connection & implementation of AP or station mode | |
| 6. Achieve a really intelligent control that achieving any cloud connection and analyze data | |
| 7. Connected directly with the gateway routing, without a separate connecting devices equipment | |
| 8. Good stability, small size, ease of integration | |
| 9. Convenient and concise, highly cost effective | |
| 10. Fast delivery and Excellent Service | |
| Quality control | Strictly tested one by one to make sure all the goods best quality Each item has been checked and in good condition before shipping |
| Advantage | Competitive Price, Fast delivery, Excellent after-sales Service |
| Payment method | T/T, Western Union |
| Shipment terms | EX-WORKS Shenzhen/Hongkong |
| Place of Origin | Shenzhen, China |
| Applications | Imaging platforms(printers, digital still cameras, digital picture frames) Consumer electronic devices(DTV,DVD players,Blu0ray players, etc.) Gaming platforms, Internet of Things, WiFi/Mobile Routes, Smart Energy Systerm Connected Appliances, Set-Top Boxes |
Application
Packaging & Shipping
Packaging & Shipping of RTL8188EUS WiFi Module
