Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light
Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light

Recessed installation 3w 6w 9w 12w 18W Small Round LED panel light

Share on (60782361874):


Price:

Quantity:


Product Overview

Description


Specification

New Lights' LED panel light is a high-end interior lighting. The Panels' design is simple but appealing. It uses high quality LED chips, PP diffuser plate of high transmission rate and a PMMA light guide plate (LGP) which facilitates a perfect transmission and diffusion of light glowing on a plan with no dark area and light leakage at the edges. It has optical feature of 110 degree beam angle, lumen efficacy of 80lm/w, Ra 80 and power efficiency >90%. Finished panels are required to pass stringent optical parameters and electrical properties examination and they are well certified with CE. The product life time can reach 50,000 hours and they are guaranteed with 2 years warranty. Customized packaging and optical parameters can be offered on customer request. The panels are suitable for lighting in hotels, offices as well as residential buildings to create a luxurious atmosphere and to enhance optimal lighting in reducing tiredness under intense or uneven lighting.

\t
Round LED panel light
\t
LGP
\t
PS Nano
\t
rated voltage
\t
85-265V
\t
material
\t
12W
\t
LED Chip
\t
SMD2835
\t
CRI
\t
80
\t
temperature
\t
3000-6500K
\t
Pf
\t
0.5/0.9
\t
Shelf life
\t
2 years
Product Description
\t
Model
\t
Size
\t
Rated Power
\t
Lumen
\t
Ra
\t
XGYPLR001-E3
\t
Φ65mm / Φ85mm
\t
3W
\t
160 lm
\t
70/80
\t
XGYPLR001-E6
\t
Φ100mm / Φ120mm
\t
6W
\t
360 lm
\t
70/80
\t
XGYPLR001-E9
\t
Φ125mm / Φ145mm
\t
9W
\t
600 lm
\t
70/80
\t
XGYPLR001-E12
\t
Φ150mm / Φ170mm
\t
12W
\t
840 lm
\t
70/80
\t
XGYPLR001-E15
\t
Φ170mm / Φ190mm
\t
15W
\t
1200 lm
\t
70/80
\t
XGYPLR001-E18
\t
Φ205mm / Φ225mm
\t
18W
\t
1440 lm
\t
70/80
\t
XGYPLR001-E24
\t
Φ280mm / Φ300mm
\t
24W
\t
1900 lm
\t
70/80
Applications
Certifications
Company Information

Related Products

LED FILAMENT BULB

LED TUBE/ FIXTURE

LED PANEL LIGHT

FLUORESCENT LIGHT

VINTAGE EDISON BULB

SMD LED BULB

FAQ

Q1. Can I have a sample order for round LED panel light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the round LED panel light lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for round LED panel light order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the round LED panel light and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for round LED panel light?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on round LED panel light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the round LED panel light?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the round LED panel light faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
