mobile mini mix wet concrete batching plant with silo 60 ton
US $48000-$50000
Portable concrete mixing equipment 750L twin shaft mixer machine 35m3/h Mobile Concrete Batching Plant price
- Category: Concrete Batching Plant >>>
- Supplier: Fujian Xinda Machinery Co. Ltd.
Share on (60782444456):
Product Overview
Description
Welcome to XDM
Portable concrete mixing equipment 750L twin shaft mixer machine 35m3/h Mobile Concrete Batching Plant price
Specifications
Mobile Concrete Batching Plant YHZS35
1. Production Capacity: 35m3/h
2. Ce,ISO,SCG certification
3. SIEMENS PLC + IPC
4. 750L twin shaft concrete mixer
XDM 35m3/h Mobile Concrete Batching Plant price YHZS35:
Mobile concrete batching plant is an innovation portbale concrete mixing equipment designed to fulfill a variety of applications.
XDM YHZS series mobile Concrete Batching Plant has the feature of instant trailing, instant stop, reasonable structure, well function, reliable working, convenient operation, accurate scale. It’s an ideal model for distance construction projects like buildings, roads, bridges, ports and any other small-scale projects.
YHZS35 is the most preferred model of XDM Mobile Series in terms of capacity. XDM YHZS35 Mobile Concrete Batching Plant with JS750 twin shaft mixer has 35m3/h production capacity and could be equipped with 50-100 tons cement silo.
YHZS35 Portable concrete mixing equipment 35m3/h Mobile Concrete Batching Plant price:
YHZS35 mobile ready mix Concrete Batching Plant is based on the advantage of many models in China and overseas and the advanced technology, combing the experiences in the past years.
1. Movable chassis structure allows a easy and convenient transportion
2. SIEMENS PLC, touch screen and computer control system with free auto/manual transfer are available for this kind of mixing equipment
3. Simple machine structure, easy to handle
4. Hydraulic type of supporting legs make it easier to adjust the whole plant
5. Quick installation as the modular design
6. High accuracy Amercian TOLEDO load cell
Technical Parameters of XDM 35m3/h Mobile Concrete Batching Plant YHZS35
Model | YHZS35 | |
Production(m3/h) | 35 | |
Twin shaft Concrete Mixer | Model | JS750 |
Mixing power(kw) | 2*18.5 | |
Output capability(m3) | 0.75 | |
Aggregate size(mm) | ≤60 | |
Hopper | Hopper capacity(m3) | 5 |
Hopper quantity | 4 | |
Trailing speed ( km/h) | 15 | |
Scope and precision of weighing
| Aggregate(kg) | 1500±2% |
Cement(kg) | 450±1% | |
Water(kg) | 150±1% | |
Additive(kg) | 20±1% | |
Total power(kw) | 70 | |
Height of discharge(m) | ≥2.8 | |
Note: If you want this concrete batching plant with 3.8m discharge height, we also can do it as per your standard.
Related Products
Click the picture to see the details:
50m3/h concrete batching plant |  60m3/h concrete batching plant |
90m3/h concrete batching plant |
120m3/h concrete batching plant |
180m3/h concrete batching plant |
240m3/h concrete batching plant |
 Mobile concrete batching plant |
Mobile Stabilized soil mixing plant |
|
Product Description
Details of Portable concrete mixing equipment 35m3/h Mobile Concrete Batching Plant price:
The aggregate batching and conveying system, water and additive supplying and weighing system, mixing system, electrical control system and pneumatic system are centralized in one trailerized chassis. It enable 35m3/h mobile concrete bathcing plant can be moved by one truck trailer.
Company Information
FAQ
Q1: Are you a factory or a trading company?
A1: We are a factory, and we have our own oversea dept. We manufacture, sell and supply after-sale service of Stationary Concrete Batching Plants, Mobile Concrete Batching Plants and Subgrade materials continuous mixing plant.
Q2: What kind of service do you offer?
A2: Pre-sales service:
1.24/7/365 to reply your inquiry.
2.To know what you needs, and suggest the correct equipment to you.
3.Sort out the layout drawing and quotation.
After-sales service:
1.To inform our clients what they should prepare before our batching plants arrive the job site.
2.Dispatch an experienced engineer to guide the installation, commissioning and training on-site.
3.The standard spare parts are in stock, and can be sent out by DHL, TNT in 48 hours.
4.Our service engineer will on-line support you when you experience the problem. Helpline is available 24/7/365
5.Regular onsite visit.
Q3: How about the installation and commissioning on new purchases?
A3: We will send our technicians to your place to guide the installation and commissioning of concrete batching plant, and also training your operator how to operate. Normally, it will take 7-10 days to erect the Mobile Concrete Batching Plants, but it depend on the condition of the jobsite.
Q4: what’s the leading time for brand new Concrete Batching Plants?
A4: Within 30 days after receipt of the 30% TT down payment or 100% irrevocable L/C at sight without “soft clauses”
Q5: Why choose us?
A: 1. We are professional manufacturer of concrete batching plant for over 20 years. (Alibaba store 14 years).
We can supply you the high quality product with reasonable price.
2. As a factory, We have our own professionals and technicians to handle development, design, production, sales and service;
3. We have certification of CE and ISO9001: 2008.
4. Famous brand accessories: TOLEDO, AIRTAC, SICOMA, WAM, SIEMENS and SCHNEIDER...
5. Long time guarantee: 12 months;
6. Perfect pre-sales and after-sales service;
7. We combine our experience with European technology to improve our machinery quality.
8. Our customers are all over the world, especially the Africa, Middle East, South America, Southeast Asia, Australia, Russia, etc, and received very well feedback from them.
