Sinocastel LT 163LE CE FCC PTCRB Certifications Wiring 3G 4G Hard Wired GPS Tracker with Android and IOS APP
- Category: >>>
- Supplier: Sinocastel Co. Ltd.
Share on (60782546370):
Product Overview
Description
Product Description
LT-163L is a 4G / Cat.M1 vehicle GPS Tracker with wide range voltage input, compact size, and built-in GPS/LTE antenna. The GPS
tracking device is ideally suitable for motorcycle, scooter, ebike and common vehicles in the anti-theft and GPS tracking
solutions.
tracking device is ideally suitable for motorcycle, scooter, ebike and common vehicles in the anti-theft and GPS tracking
solutions.
Features:
* Wide range voltage input range: DC 9-90V
* Supports GPS/Beidou dual-mode positioning
* Support OTA upgrading, reduce maintenance on site
* Industrial class components with high quality
* Built-in G-sensor to save the power in the sleeping mode and anti-theft reminding
* Comprehensive data collection and analysis, including location data and driving behavior data
* Wide range voltage input range: DC 9-90V
* Supports GPS/Beidou dual-mode positioning
* Support OTA upgrading, reduce maintenance on site
* Industrial class components with high quality
* Built-in G-sensor to save the power in the sleeping mode and anti-theft reminding
* Comprehensive data collection and analysis, including location data and driving behavior data
Applications
1. Fleet management and vehicle tracking
2. Car service shop
3. Vehicle insurance
4. Car rental
2. Car service shop
3. Vehicle insurance
4. Car rental
5. Motorcycle / Motorbike / Scooter / E-bike
Specification
HARD WIRED GPS TRACKER for Motorcycle / Motorbike / Scooter / E-bike | ||
Size | 75mm (L) x 48mm (W) x 20mm (H) | |
Weight | 50g | |
Power and I/O | Battery+, Ground, ACC input and Relay control on a 4 pin connector | |
Configuration Port | Micro-USB | |
SIM Card Socket | Micro SIM, Push-Push Type | |
Data transmission | Packet data (LTE) and SMS | |
Positioning method | GPS | |
Storage | 2MB FLASH, up to 24,000 GPS data storage | |
Working Voltage | 9-90V/DC | |
Working Current | Max.: <200mA@13.8/27.6VDC Average: <150mA@13.8/27.6VDC Sleep mode: <10mA@12/24VDC | |
Backup battery | 3.7V/160mAh | |
GPS | Channels: 66 Sensitivity: -165dBm Accuracy: 5m CEP Time to first fix: Cold start: <30s (typ.) Hot start: <1s (typ.) | |
Cellular | Frequency: FDD LTE B4/B13 (Verizon) FDD LTE B2/B4/B12 (AT&T) Data: CAT M1: DL/UL Max. 300/375kbps Network protocol: Embedded TCP/IP stack Certification: GCF, FCC, PTCRB, IC, Verizon, AT&T | |
6-axis IMU | Driving behavior detection | |
LED Indication | GPS/Cellular/Power indication | |
Cellular | Internal | |
GPS | Internal | |
Working Temperature | -30℃ ~ +70℃ | |
Storage Temperature | -40℃ ~ +85℃ | |
Humidity | 5%～95%（no fog） | |
Packing & Delivery
Company Profile
Established in 2007,Sinocastel is a national high-tech manufacturer integrating R&D, production, sales & operation,focusing on the research and production of GPS telematics and solutions.
Our main products include: obd tracker,GPS/ Beidou trackers for all kinds of vehicles, hardwired GPS tracker, asset GPS
tracker,T-BOX, children & elderly smart watch and GPS tracker, and pet GPS tracker,which have one or more communication modes such as GSM, CDMA, WCDMA, and LTE. The hardwares and solutions have been widely used in fleet management, car insurance UBI,telecom industry, car rental business and family care service.
Our company's sub-meter car GPS/Beidou tracker has excellent performance with low cost and high precision.All products have different domestic and international standards for different countries, such as CCC, CE, FCC, Rohs, EMARK,NATEL,AT&T, PTCRB, JATE and TELEC certifications.
Our main products include: obd tracker,GPS/ Beidou trackers for all kinds of vehicles, hardwired GPS tracker, asset GPS
tracker,T-BOX, children & elderly smart watch and GPS tracker, and pet GPS tracker,which have one or more communication modes such as GSM, CDMA, WCDMA, and LTE. The hardwares and solutions have been widely used in fleet management, car insurance UBI,telecom industry, car rental business and family care service.
Our company's sub-meter car GPS/Beidou tracker has excellent performance with low cost and high precision.All products have different domestic and international standards for different countries, such as CCC, CE, FCC, Rohs, EMARK,NATEL,AT&T, PTCRB, JATE and TELEC certifications.
FAQ
Q1.Do you accept OEM and ODM order?A: Yes, OEM and ODM order are welcomed. We have our own R&D team located in ShenZhen and HongKong. Our factory is located in Baoan,Shenzhen.
Q2.How about the quality of your device?
A: Most of our products have been approved by CE,FCC,PTCRB,CCC and Anatell certification to ensure good quality and stable performance.Our factory passed ISO9001:2015 and TS16949 quality management control system of strict production process.
Q3. What’s the warranty?
A: The warranty is 1 year.
Q4. What’s the lead time?
A: For samples: 1-2 days against full payment arrival. For bulk Orders: 4-6 weeks against the deposit arrival.
Q5. What’s the shipping time?
A: Normally is 3-5 days from DHL/Fedex/UPS/TNT door-to-door services.
Q6. What’s the payment method?
A: You can pay via PayPal, Western Union and Bank transfer.
Q2.How about the quality of your device?
A: Most of our products have been approved by CE,FCC,PTCRB,CCC and Anatell certification to ensure good quality and stable performance.Our factory passed ISO9001:2015 and TS16949 quality management control system of strict production process.
Q3. What’s the warranty?
A: The warranty is 1 year.
Q4. What’s the lead time?
A: For samples: 1-2 days against full payment arrival. For bulk Orders: 4-6 weeks against the deposit arrival.
Q5. What’s the shipping time?
A: Normally is 3-5 days from DHL/Fedex/UPS/TNT door-to-door services.
Q6. What’s the payment method?
A: You can pay via PayPal, Western Union and Bank transfer.
