round steel forming brake tube with fittings

Share on (60782888548):


Price:RUB 26.02 - RUB 33.45

Quantity:


Product Overview

Description

Product Name
round steel forming brake tube with fittings
Standard
Cooper-standard, Ford-standard, GM-standard, Jingda standard
Out Diameter
4.76mm~12mm
Wall Thickness
0.7mm, 1.0mm
Length
Cut to length, Any length as your requirements
Material
Low Carbon Steel/BHG2, copper
Usage
For automobile and refrigeration industry
Packing
Coils or Bundles ,then in pallets or wooden boxes
Water-proof packing, using plastic film for inner package , and plastic woven bag for outside package,and then put them in the wooden box
MOQ
2 Metric tons, aometimes can be negotiated by two parties
Payment terms
T/T
Surface Treatment
Galvanization: white zinc, Olive zinc, colored zinc; PVF coated; PA12(nylon) coated; Copper coating tube; ALGAL
Export to these countries
USA/UK/Canada/Brazil/India
Certificate
ISO/TS 16949:2009

Specifications


Type
Typical appearance
Aiti-corrosion
Copper tube
Bright or light blue
6-8h
White zinc tube
Rainbow and white
24-36h
Color zinc tube
Yellow rainbow
72-96h
Olive green tube
Olive green or bronze color
96-144h
PVF tube(mainland)
black/green
≥1000h
PVF tube(abroad)
3000-5000h

Machanical Properties.

Tensile Strength
≥290Mpa
Yield Strength
≥180Mpa
Elongation
≥25%
HR30T
≤68
Inside Surface Cleanliness
≤0.16G/m2
More Images

Usage:

Our customers
Our Company

Jingda (Jingda) Aotomotive Co., Ltd. is located in Jingzhou, hubei province, China. We produces all kinds of automotive tubing, including double-wall brazed tubes of different specifications and wall thickness, as well as various galvanized pipes, polyvinyl fluoride coated pipes(PVF), nylon (PA12) coated pipes, hot dip galvanized aluminum alloy coated aluminum-rich epoxy resin pipes(ALGAL)and aluminum-rich epoxy resin coated pipes etc.

We manufacture products under Cooper-standard and Ford standard more than 20 years, and have been the stable supplier of Ford, Cooper, Volkswagen etc. Stable and sustained quality and services will be provided.

Our Service

1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.

FAQ


Q1. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q2. What is your terms of delivery?
A: FOB


Q3. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
