1. Smart uniform irradiation solution improves image quality & monitoring effect for night vision
2. Leading IR technology provides high efficiency and long life span of LED
3. Accurate constant circuit drive develops excellent performance of product
4. Power and day/night switch manually controlled
5. Support to all kinds of box camera
6. Indoor/outdoor use, all-weather use
7. High integrated solution for easy installation and saving cost
Quantity of LED: 10PCS 2W High Power IR LED
Wavelength: 850nm
Beam Angle: 15°- 90°
IR Distance: 160m-50m
Day/night Switch: CDS 10-20lux ±10% (adjustable)
Input Voltage: AC110-220V
Output Voltage: DC12V 1000mA
Power Consumptionv 22W (adjustable)
Panel: Tempered glass panel
Housing: Aluminum Die Casting Housing
Bracket: Bottom mount bracket
Working Temperature: -40℃ to +60℃(-50℃ to +60℃ with heater)
Cooling: Air cooling internal circulation
Blower: Included
Protection Level: IP66
Color: Beige
N.W: 3.3KG
G.W: 3.85KG
Dimension: 445*190*132mm
Packing Dimension: 482*225*170mm
Model for Selection
Model Beam Angle *IR Distance(850nm)
S-LD042-15A 15° 160m
S-LD042-30A 30° 120m
S-LD042-45A 45° 90m
S-LD042-60A 60° 80m
S-LD042-90A 90° 50m
*IR distance is tested by SONY 1/3" CCD Camera with 0.01lux.
*To achieve the distance needed, please pay attention to your camera specification and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens.
