  • Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine
Mini 12V/24V DC Gear Motor for Water Vending Machine

Mini 12V/24V DC Gear Motor for Water Vending Machine

Share on (60784676420):


Price:$16.00 - $18.00

Quantity:


Product Overview

Description


Product Description

Product Application

This small gear motor is designed to be small size,low noise,easy installation.The mini 12v dc gear motor is widely used for vending machine,automatic microwave oven,ATM machine,bank equipment,BBQ oven and other home appliance.

\t
SPECIFICATIONS FOR 12V MICRO GEAR MOTOR
\t
Name
\t
small geared motor
\t
Rated Current
\t
0.35A
\t
Model
\t
GA24-301D-011
\t
Rated Speed
\t
1.45rpm
\t
Input Power
\t
12VDC/24VDC
\t
 No Load Noise (dB)
\t
less than 45
\t
Reduction Ratio
\t
915:1
\t
Feature
\t
Lower Noise/small Body
\t
Rated Torque
\t
>80kgf.cm
\t
Gear material
\t
Powder metal
\t
Motor Speed
\t
1750rpm
\t
Stall Torque
\t
>200kgf-cm
\t
No Load Speed
\t
1.9rpm
\t
Stall Current
\t
<1.1A
\t
Rotation Direction
\t
CW/CCW
\t
Gear box material
\t
High quality zinc alloy

Main Features

1) Low noise.

2) Small body.

3) Powder metal gear inside.

4) High quality zinc alloy gear box

5) Can be applied for various kinds of small automatic equipment.
