Police and military style binocular night vision binocular camera with laser rangefinder
- Category: Telescope & Binoculars >>>
- Supplier: Zhejiang Dali Technology Co. Ltd.
Share on (60784739014):
Product Overview
Description
As a listed company focus on infrared technology for more than 30 years. Produce thermal detector, thermal module, handheld thermal camera, thermal monocular, thermal binocular, thermal weapon sights, thermal CCTV camera, thermal network camera, etc.
Have R&D team to solve complex situation. Welcome to our R&D base to discuss the application and technology of infrared or your concerns requests.
Selling points
• Cooled multi-functional handheld 24/7 day&night surveillance thermal binoculars
• High sensitivity
• Ultra-long-range observation
• Motorized continuous zoom
• IP 67 class
• Binoculars OLED display
• Photo&Video record
• With GPS
• With laser range finder
• Digital magnetic compass
• CCD & Thermal channel
Specification
Detector | Detector type | MCT cooled detector | |
Spectral range | 3 ~ 5 µm | ||
Array size | 320×256 | ||
Pitch size | 30µm | ||
NETD | ≤30mk@25℃ | ||
MRTD | ≤0.35℃ | ||
Lens | Focal length | 24~240mm F4 motor continuous zooming | |
FOV | 2.3° ×1.8° ~ 23° ×18° (±5%) | ||
Image and storage | Gain/brightness | Manual/auto | |
Calibration | Auto calibration when start up | ||
Enhance | Yes | ||
Smoothing | Yes | ||
Polarity | Black/White-Hot | ||
Focus | Motor | ||
Storage | Storage type | Built-in storage card 8GB | |
File type | Image & Video | ||
File format | JPG & AVI | ||
Capacity | Image: ≥1000 Video: ≥2h | ||
Display | Displayer | Binocular OLED displayer(800x600) | |
Eyepiece diopter | -4 ~ +4 | ||
Information processing | Positioning system | GPS | |
Positional accuracy (RMS) | Latitude-longitude: 5m | ||
Electronic compass | Horizontal range:360° | ||
Angular accuracy (RMS) | Azimuth: 0.6° | ||
Laser range finder | Wavelength band | 1.55 µm(Safe for eyes) | |
Ranging | 50m~8Km | ||
Ranging accuracy: | ≤2m(Target>50m) | ||
Distance distinguish | ≤30m | ||
Accuracy rate | ≥96% | ||
Working frequency | 10/min | ||
Target positional accuracy (RMS) | ≤30m(8Km) | ||
Visible camera | Senor | 1/3”HAD CCD | |
Resolution | 795×596 | ||
Illumination | 0.05 Lux | ||
Resolution | 600 TVL | ||
Focal length | f=100mm,F=2.6 | ||
FOV | 2.85°×2.13°(±5%) | ||
Environment | Working temp | -30℃~55℃ | |
Storage temp | -40℃~65℃ | ||
Protection level | IP67 | ||
Power | Battery type | Li-ion, rechargeable | |
Battery working time | > 4 hours (@25℃) | ||
Physical characteristics | Weight | ≤4Kg | |
Dimension | 278×250× 110mm | ||
External power | Yes | ||
External video | PAL | ||
Date transmission | USB | ||
Communication | RS232 | ||
Installation | 3/4"-20-UNC | ||
Detection distance | Human(1.7*0.5)m | 6600m | |
Vehicle(2.3*2.3)m | 9000m | ||
Recognition distance | Human(1.7*0.5)m | 2200m | |
Vehicle(2.3*2.3)m | 3000m | ||
