Normal cnc new condition automatic low price small high quality KYZ30C conventional drilling machine
- Category: >>>
- Supplier: Yangzhou Kaiyun Machinery Co. Ltd.
Share on (60784812104):
Product Overview
Description
Product Description
Specification | ||||
Model No. | KYZ30 | KYZ30C | ||
Max. drilling capacity | 32mm(MT3) | 32mm(MT3) | ||
40mm(MT4) | 40mm(MT4) | |||
Max. end milling capacity | 32mm | 32mm | ||
Taper of spindle bore | MT3 or MT4 | MT3 or MT4 | ||
Spindle stroke | 120mm | 120mm | ||
Headstock swivel left & right | ±90° | ±90° | ||
Step of spindle speeds | 12 | 12 | ||
Range of spindle speeds | 75-3200mm | 75-3200mm | ||
Table size | 540X470mm | 600X190mm | ||
Table travel | X-360mm | Y-190mm | ||
T-slot width | 14mm | 14mm | ||
Table stroke up & dowm | 620mm | 520mm | ||
Diameter of column | 115mm | 115mm | ||
Max distance spindle to table | 715mm | 610mm | ||
Distance between spindle to column | 272mm | 272mm | ||
Max distance spindle to base | 1180mm | 1180mm | ||
Motor | 1.1KW | 1.1KW | ||
Packing size | 740X720X1830mm | 820X720X1830mm | ||
Net weight | 320kg | 340kg | ||
Optional Accessories | ||||||
Power feed | 1pc | |||||
Cooling system | 1set | |||||
58pcs clamp kits | 1set | |||||
milling vise | 1pc | |||||
drilling vise | 1pc | |||||
Keyless drill chuck | 1pc | |||||
Features
1.Milling, drilling, tapping boring and reaming;
2.head swivels 360 degree. Table swivelled 180 degree and tilted 45 degree;
3.Super high colum;
4.Equipped with cross table or Big&wide table; Cross table may be elevated up and down by geared crank handle;
5.Micro feed precision;
6.Heavy-duty tapered roller bearing spindle;
7.High precision ground spindle and larger quill etc.
