Factory manufacturing medical grade TPU high pressure braided monitoring line

Product Overview

Description

Product Description

The High Pressure Braided Tube (or says High Pressure monitoring line) is used to inject contrast media, and the other medical solutions during PTCA procedure, PCI procedure or Angioplasty procedure.





Product Usage

The product is used for pressure monitoring line connections as a connection between line and instruments.



Product Specification

OD = 3.65mm,  ID = 1.8mm

Length = 25cm, 30cm, 50cm, 75cm, 100cm, 120cm, 200cm, 250cm or custormized.

* Reinforced with braided nylon monofilament.

* Two layers TPU (Thermoplastic polyurethane).

* Standard PC Luer M / F locks with Silicone O Ring.

* 360 degrees high joint with silica gel pad rotate.

* Constant working pressure of 1200 psi (83atm).

* Burst pressure exceeding 1500 psi (102atm).

* Resistance to bending.

* Custom sizes available.

* Sterile or Non Sterile, depends on customers.
