Sunta Cheap Rack-Mounted VGA Real-time 16CH Video Splitter Color quad multiplexer

First, system characteristics
    1. 4 audio inputs,1 audio output (some products include this function)
    2.16 video inputs:Can adjust the brightness,contrast,saturation,chroma and sharpness of each camera channel separately
    3. High resolution:
               PAL system: 720x576 50Hz
               NTSC format: 720x480 60Hz
               VGA (optional) output: 1024X768
     4. Multiple display modes
               Four-screen, eight-screen/16-screen display
               Single screen full screen display
               PIP display mode: 1 PIP, 2 PIP (adjusts each video channel as a PIP display)
               Automatic sequential display mode (the display time of each screen can be set independently)
              Two video channels can be freely selected for contrasting cruise monitoring
      5. Freeze the screen
      6. Enlarged display (×2), freely selectable zoom area
      7. Diverse information display: Camera name, time, date, screen loss alarm information
      8. Screen playback (VCR IN/OUT requires video recorder)
      9. Various alarm events
             1), video loss and motion detection, 60 event record reports, built-in buzzer
             2), 8 external alarm inputs, 1 external alarm output (some products include this function)
      10. Support infrared remote control
      11. Control the PTZ via RS485 interface
      12.Support RS485/RS232 to control the machine, the number of control is up to 255 units

Cheap Rack-Mounted VGA Real-time 16CH Video Splitter Color quad multiplexer Specification:
Video system
NTSC/PAL
Real time
YES
Image refurbish rate
PAL: 25f/s; NTSC: 30f/s
Video standard
PAL:720×576,25f/s; NTSC:720×480,25f/s
Total Resource
PAL: 150*4 f/s; NTSC: 180*4 f/s
Language
Chinese/english
Video input
9 channel video signal input,apex:1Vp-p,impedance:75Ω/1 channel video playback video signal input,apex:1Vp-p,impedance:75Ω
Duplex
Yes
VCR connector
BNC connector.one input one output
Loop through
16 channel loop through
Video output
one channel BNC main minitor output.apex:1Vp-p,impedance:75Ω/one channel BNC assistant monitor output,apex:1Vp-p,impedance:75Ω/one channel VGA main monitor output(optional)
Audio
RCA connector,4 input one output
Communication
RS485 Cradle head,RS232 controlled
Keyboard control
Support,Work bitspersecond :9600bps
Auto switch time
0~99 second
Video Adjustment
Brightness,contrast,saturation,Hue,Sharpness can be adjusted
Event recorder
support 60 groups
Operation manner
Front panel,remote controller,computer,keyboard control
Power consumption
DC12V,12W
Working environment
Temperature:10~60℃, Humidity: 10%-90%
Gross weight
2.4 kg
