AUTOMATIC RUBBER/TR/TPU INJECTION MOULDING MACHINE

Product Overview

Description



STRONG MACHINERY CREATION Co., Ltd

(NO.42 Xitou Village He Shi Town-Area Luojiang District ,Quanzhou City Fujian, China)

2017 double colors Rubber Soles Auto Oil Hydraulic Machine supplier out-soles Making Machinery manufacturer















Automatic rubber/tr/tpu injection women HELL and men sole moulding machine

1. This machine was designed to be incorporated with mini computer inside ,it has higher automatic computation and detedtion and more security of the whole machine .it has a friendly dialog interdace,very easy for the operator to handle iy.

    2.   This machine is applicate to product many kinds of high quliyu shoes materials with different materials.It’s the best choice of you company to keep good competitiveness and upgrade the facilities.





PRODUDTION OF INFORMATION OF THE SHOE MOULDING MACHINE
Model	Unit	SC206N1
Material	TEA TPU TR TPR PVC
Work stations	station	6
Mould-Close Pressure	Ton	100
Diameter of Screw	Mm	65
Injection Cap.(Max)	G	900
Injection Pressure	Kg/cm2	0~800
Injection Speed	cm/sel	0~10
Rotating Speed of Screw	R.P.M	0~165
Temperature Control	Station	4
Heater of Barrel	Kw	5.5
Heating board of mould	kw	38.4
Total Electricity	Kw	63
Oil Tank Size	L	800
Dimension L*W*H	MM	5500*4390*2100
Machine Weight	Kg	13200
