Product Overview

Description


Product Description

model ZQZ5310TFC synchronous road machine chip sealer asphalt distributor equipment

\t
Mass parameter
\t
Kerb Weight(kg)
\t
21200
\t
Total Weight(kg)
\t
31000
\t
Rated loading Weight(kg)
\t
9670
\t
Dimension(mm)
\t
12000×2500×3730
\t
Chassis Parameter
\t
Chassis Model
\t
Z1317ZM4661V
\t
Tyre model
\t
12.00-20
\t
Wheelbase (mm)
\t
1800+4600+1350
\t
Tread (mm)
\t
2022/1830
\t
Engine parameter
\t
Engine model
\t
WD615.87
\t
Manufacturer
\t
China Heavy Duty Truck Group Co., Ltd.
\t
Max.Power(kw)
\t
213
\t
Max. Torque(N.m)
\t
1300/1600
\t
Fuel
\t
Diesel
\t
Displacement(ml)
\t
9726
\t
Spray specification
\t
Tank Capacity(L)
\t
8000
\t
Chippings Capacity(m³)
\t
12
\t
Hydraulic pump model
\t
CBQL-E563
\t
Spray width
\t
3800mm
\t
Hydraulic motoe
\t
L2F63W2P2(LIYUAN)
\t
Spray Value
\t
0.5-3.0(Kg)
\t
Controller
\t
ZMTB-3D
\t
Insulation Thickness
\t
50mm
\t
Generator(Converter)
\t
YT6800E(YITENG)
\t
Nozzles
\t
28
\t
Asphalt pump
\t
QGB450(SHANGGUI)
\t
Burner
\t
G20(Riello)
Related Products

Chip Sealer ZQZ5250TFC

Surfacing & Slurry Micro Paver

Mechanical Tire Type Asphalt Paver

Intelligentized Asphalt Distributor

Manual Asphalt Distributor

Chipping Spreader

Detailed Images
Certificate
Company Profile

Hangzhou IKOM Construction Machinery Co., Ltd is located in Hangzhou, it was the branch company of CHINA NATIONA COMMERCIAL AUTOMOBILE CO.,LTD(CACAC), The CNCAC passed the ISO9001:2008international quality system certification and products 3C authentication, the products cover semi-trailer, dump truck, car, transportation, tank car transport, waste garbage collection vehicles and a waste transfer station equipment sanitation equipment), a. (flow stage car, cinema, books, such special cultural car, mobile power, electrical power, such training, medical treatment of municipal tractors a. a. etc, a total of 150 various models, and gradually realize the product standardization and serialization and industrialization.

Our Advantages

PERFORMANCE

1 Nozzle:
a) Installation of stainless steel nozzle, can be positioned correctly and easy to replace
b) Stainless steel nozzle be used more time than other nozzle.
c) When spraying asphalt, bitumen consumption can be reduced and keep the quality of spray keep the
2 Heat Conducting Oil System:
a) The new Heat Conducting Oil System can heat asphalt and pump faster
b) Especially in use of spraying emulsified asphalt,speed up the heating efficiency and save fuel
3 Controller:

a) Control system is more friendly and easier to be operated.
b) Intelligentzied model is suitable for asphalt pavement construction which can improve performance achievement of the international advanced standard..
4 Cleaning:

Can use diesel fuel or high-pressure air cleaning of pipes and pumps
5 Environmental protection, reduce the consumption:

In the spraying end, using high pressure air makes asphalt of residues in pipe row back to the tank, Avoid residual asphalt pollution of the environment, and save the asphalt consumption.
