Product Overview

Description


drop ship WS2812B LED strip w2812b tira led 30leds per meter flexible 5050 led strip light
































































Model number


TS-10030-WS2812B


 LED TYPEE


SMD 5050  RGB  chip


Available color


RGB


IC Model


WS2812 (WS2812 IC built -in 5050  RGB led chip )


Color


Addressable full color


View angle


120 degree


LED QTY


30LEDS/M


POWER


7.2W


Voltage


DC5V


PCB width


10mm


Installation


wiht 3M adhesive back ,easy for installation


IP rate


IP20/IP65(Silicon tube )/IP67/IP68


Package


5M/reel .with anti-static bag


Application


indoor /outdoor decorative lighting  ,ceiling lighting ,sign lighting etc.







Detail use information:


WS2812B LED strip w2812b tira led 30leds per meter flexible 5050



1)Addressable full color led strip (WS2812B) ----WS2811 ic built-in 5050 RGB led chip

2)30pcs led per one meter

3) individually control ----------1 ic& 1 led chip

4)same as our WS2801or APA 102C addressable strip ,this one cut-able each single led .
5)Sticky: with 3M adhesive on back side for sticky.

     screw+silicon clip, or 3M adhesive back side.







Connection:


WS2812B LED strip w2812b tira led 30leds per meter flexible 5050


SPI signal :LED strip+ LED power  supply +led controller
DMX  control :LED strip + LED power supply+DMX controller +DMX decoder

LED controller :T-series SD card controller ,RF remote controller .DMX controller,Arduino.........(off line /PC online)

LED power supply :Meanwell power supply ,T- series ,A-series .... (waterproof /non-waterproof )





Controller and Power supply:
T-1000S  +Meanwell power:
