WEIFANG RICARDO engine Single phase 20kw 20kva diesel generator price

Share on:

Price:RUB 135,608.22 - RUB 197,535.98
Price in USD:Details


Product Overview


1-Diesel Generator2-Diesel Generator3-Diesel Generator4-Diesel Generator5-Diesel Generator6-Diesel Generator7-Diesel Generator8-Diesel Generator9-Diesel Generator10-Diesel Generator11-Diesel Generator12-Diesel Generator13-Diesel Generator14-Diesel Generator15-Diesel Generator

Diesel generator set   Silent / Soundproof type / Open type / Trailer type/ Container type

Safety – Stability – Economy -  Reliability Power

1. Our cooperate with famous diesel engine –Powered by USA Engine, UK Brand Diesel engine  Deutz , LovoL , Lister Petter, Doosan, Shangchai, Yarman, Foton-Isuzu, Xichai, SDEC, Weichai, MTU, Ricardo, Jichai.

2. Equipped with famous Brushless alternator – Optional Stamford, Leroy Somer, Marathon, JET, Mecc alte.

3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working

4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,

5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM

6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing

7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.

8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.

9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker

10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.

11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance

12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.

13. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.

Diesel generator set   Silent / Soundproof type / Open type / Trailer type / container generator

Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard

Diesel generator Prime output power: from 5KVA to 2500KVA

Rated voltage: 120V/240V, 220/380V, 230V/400V, 254V/440V etc. other voltage is optional

Generator Phase and connecting: 3 phase, 4wire.

Rated frequency: 50Hz@1500rpm  or  60Hz@1800rpm

Alternator excited type: Brushless, self excited or PMG optional

Alternator Insulation: Class H

Alternator Protection: IP21 ~ IP23

Voltage regulation: AVR automatic control 1%

Altitude above sea level:  ≤1000 meters

Ambient air temperature:  ≤40°C

Relative air humidity:  ≤ 90%


Technical Data


Model 400V / 50Hz / 1500RPMRicardo and Shanghai Diesel Engine 1500rpmAlternator
Standby outputPrime OutputModel / OutputEngine typeDisplacementBore×StrokeBrushless Alternator
KVAKWKVAKWNo. of CylinderGovernor(L)(MM)
GF-1111 8.8108K2105DL2Mechanical1.63105×115WP164B
GF-1514 111310K2105DL2Mechanical1.63105×115WP164C
GF-1717 13.21512K4100DL4Mechanical3.61100×115WP164D
GF-2121 16.519 15K4100DL4Mechanical3.61100×115WP184E
GF-3028 222520K4100DL4Mechanical3.61100×115WP184F
GF-3333 263024K4100DL4Mechanical3.61100×115WP184G
GF-4141 333830K4100ZDL4Mechanical3.61100×115WP184H
GF-5555 445040R4105ZDL4Mechanical4.33105×125WP224D
GF-7069 556350R4105AZDL4Mechanical4.5105×125WP224E
GF-10096 778870R6105ZDL6Mechanical6.49105×125WP224G
GF-110110 88 100 80 R6105ALDL6Mechanical6.75105×130WP274C
GF-125125 10011390R6105ALDL6Mechanical6.75105×130WP274D
GF-140138 110125100R6105IZLDL6Mechanical7.1105×135WP274ES
GF-165165 132150120R6110ZLDL6Mechanical7.52110×135WP274F
GF-206206 165188150R6113AZLDL6Mechanical7.82113×135WP274G
GF-250248 198225180R6126ZLDL6Mechanical9.73126X130WP274J
GF-275275 220250200R6126ZLD-1L6Mechanical9.73126X130WP274K
GF-330330 264300240618ZLDL6Mechanical11.6126X155WP444D1
GF-350344 275313250618AZLDL6Mechanical11.6126X155WP444E
GF-413413 33037530012V135AZLD /SDV51012VElectric25.8135×155WP444FS
GF-500500 40045036012V135BZLD /SDV61012VElectric26.6135×155WP544C
GF-550550 44050040012V135BZLD-1 /SDV66012VElectric26.6135×155WP544D
GF-700700 560625500SY630 /SDV82012VElectric27.14135×158WP544FS
GF-825825 660750600SY720 /SDV88012VElectric29.61138×165WP634B

Controller System

1. Standard AMF control panel, including digital LED genset control model: HGM6120U, DSE7320, DSE6020, AMF20, AMF25


2. Automatic transfer switch (ATS) and Automatic parallel operation system



Standard accessories: Standard 50 degree radiator mounted on skid. Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wire, Standard tool kit, operation manual and Testing document

Manufacturing Standard

GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34.


Product Warranty policy

JET product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.
