Raman spectroscopy detector hand held explosive, drug, chemical identifier detection system in prison, airport, lab
- Category: >>>
- Supplier: Shenzhen Security Electronic Equipment Co. Limited
Share on (60787065240):
Product Overview
Description
Raman Spectrometer hand held explosive, drug, chemical detection system in prison, airport, lab
SECUPLUS offers SPE-6000 Handheld Chemical and Explosive Identifier, for rapid, accurate identification of unknown liquids and solids such as threat liquids, narcotics, explosives, and chemical warfare materials. Based on Raman spectroscopy, SPE-6000 can analyze the unknown substance in question quickly and provide an immediate, reliable result.
It can create PDF E-report or print report by Thermal Printer .
Analyze sold, liquid or powder articles as bellow :
Explosives | TNT ,RDX, PETN, Octagon, Sulfur and Ammonium Nitrate, etc. |
Liquid Threats | Acetic acid, Acetic anhydride, Ethanol, Chloroform, Methanol, Toluene, Acetone, Pyridine, Benzene, Ethyl ether, Cyclohexane, 1-2 Dichloroethane, Xylene, N,N-dimethylformamide, Isoamyl alcohol, Isopropyl alcohol, Nitrobenzene, Cyclohexanone, Isoamyl acetate, Tetrahydrofuran,etc. |
Others | infinitely extension database |
Portable explosive vapor detection
General Specification: | |
Whole device dimension | 160 X 222 X 74 mm (L*W*H) |
Weight | 2.3 kg |
Spectrum range | 200 – 3900 cm-1 |
Resolution | 8 – 10 cm-1 |
Laser wavelength | 785 nm |
laser security classification | 3B |
Detector | Backside highly-sensitive CCD detector |
Laser consumption | 0-500mWadjustment |
Display | 5.6 inch color touch screen |
100ms – 5s | |
Analysis time | 3s |
Alarm | Audio and visual alarm. And show you test result . |
Detection way | Acquiring a usable signal a few millimetres away from the sample |
Probe working focal length | 8 mm |
Warm up time | No. |
Data | By USB or wireless to import or export |
Data storage | Save 300,000 records |
Power | 12V/3A adaptor |
Battery | Rechargeable 4 hours Lithium battery
|
Working temperature | 0 ℃ to 40 ℃ |
Working humidity | ≤93% |
Storage temperature | -20 ℃ to 55℃ |
Storage humidity | ≤80% |
