High Quality 56 Ton Liquid Silicone Rubber Horizontal Plastic Injection Molding Machine
- Category: >>>
- Supplier: Suzhou Costar Machinery Co. Limited
Share on (60787550541):
Product Overview
Description
Products Description
CST1100/9500 | |||||||||
a | b | c | |||||||
Injection Unit | |||||||||
Screw diameter | mm | 110 | 120 | 130 | |||||
Screw L/D ratio | L/D | 22 | 20.2 | 18.6 | |||||
Injection capacity in theoiy | cm3 | 5321 | 6333 | 7433 | |||||
Injection weight(ps) | g | 4842 | 5763 | 6764 | |||||
oz | 170.7 | 203.2 | 238.5 | ||||||
Injection pressure | MPa | 178 | 150 | 127 | |||||
Injection rate | g/s | 804 | 936 | 1099 | |||||
Plasticizing capacity | g/s | 101 | 112 | 125 | |||||
Screw speed | rpm | 110 | |||||||
Clamping Unit | |||||||||
Clamping force | kN | 11000 | |||||||
Moving mould-plate stroke | mm | 1220 | |||||||
Max.Mould height | mm | 1170 | |||||||
Min.Mould height | mm | 450 | |||||||
Space between tie-bars | mm | 1160x1160 | |||||||
Hydraulic ejector force | kN | 245 | |||||||
Hydraulic ejector stroke | mm | 320 | |||||||
Ejector number | n | 21 | |||||||
Other | |||||||||
Pump pressure | MPa | 16 | |||||||
Motor/Driving power | kW | 45 + 45/30x3 | |||||||
Heating capacity | kW | 68.85 | |||||||
Machine dimension | m | 12.55x2.65x3.5 | |||||||
Machine weight | t | 56 | |||||||
Oil tank capacity | L | 2000 | |||||||
Product Display
Recommend Products
Company Profile
FAQ
Q1: Are you a trading company or a manufacturer?
A1: We are a manufacturer, we supply the factory price with good quality, welcome to visit !
A1: We are a manufacturer, we supply the factory price with good quality, welcome to visit !
Q2:How about quality control in your factory?
A2: “ Quality is the key point, do what customers needs”
A2: “ Quality is the key point, do what customers needs”
Q3: Is there complete machine include mould and other auxiliary equipment ?
A3: Yes ,what we are provide is the complete system and you will no need spend a lot to find the suitable water chiller and color mixer...etc.
A3: Yes ,what we are provide is the complete system and you will no need spend a lot to find the suitable water chiller and color mixer...etc.
Q4: What is the language of the PLC and touch panel?
A4: English and Chinese, or other customized language
A4: English and Chinese, or other customized language
Q5: Can you help us with the shipment of this machine ?
A5: With honor ,we have our special shipment company which already cooperate for long time, we will give you the best price we can. Also you can ask your own shipping forwarder, we help you do other things. Customer satisfy, is our target.
A5: With honor ,we have our special shipment company which already cooperate for long time, we will give you the best price we can. Also you can ask your own shipping forwarder, we help you do other things. Customer satisfy, is our target.
