SDR 630 Qingdao деревообрабатывающее оборудование, двухсторонняя деревообрабатывающая шлифовальная машина
- Category: >>>
- Supplier: Qingdao Sefe Trading Co. Ltd.
Share on (60787727237):
Product Overview
Description
Product Description
This type characters:
1.double sanding machine
2.has two heads,one top,one bottom
1.double sanding machine
2.has two heads,one top,one bottom
3. sanding width between 20mm to 630mm
-The machine is special for double-sided grinding workpiece sanding machine,with superb technology filling the gap in the market for the product,greatly reducing the expensive labor costs,reduce production cost,improving work efficiency.(Conveyor table fixed and lifting can be equipped with the production line use).
Technical Parameters
There are three types of structures, customized according to customer requirements.
Model | SDR-630 | SDR-R630 | SDR-RP630 |
Working width | 20-630mm | 20-630mm | 20-630mm |
Working thickness | 4-100mm | 4-100mm | 4-100mm |
Working length | ≥300mm | ≥300mm | ≥300mm |
No.1#sanding belt speed | 20m/s | 20m/s /20m/s | 20m/s /18m/s |
No.2#sanding belt speed | 20m/s | 20m/s /18m/s | 20m/s /18m/s |
Feeding speed | 2-16 m/min | 2-16 m/min | 2-16 m/min |
Size of sanding belt(W*P) | 650*1920mm | 650*1920mm | 650*1920mm |
Total motor power | 33.75 kw | 57.5kw | 50.5kw |
Main motor power(two/four) | 15kw,15kw | 15kw/11kw,15kw/11kw | 15kw/7.5kw,15kw/7.5kw |
Working air pressure | 0.55Mpa | 0.55Mpa | 0.55Mpa |
Consumption of comperessed air | 0.2m³/min | 0.35m³/min | 0.35m³/min |
Volume of sucked air | 4000m³/h | 5000m³/h | 5000m³/h |
Speed of sucked air | 25-30 m/s | 25-30 m/s | 25-30 m/s |
Overall dimension(L*W*H) | 1900*1900*2300mm | 1900*3500*2300mm | 1900*4000*2300mm |
Net weight | 2500kg | 4300kg | 4400kg |
Factory Video Display
Company Introduction
Qingdao Sefe Trading Co., Ltd. is a subsidiary of Sefe Woodworking Machine Manufacturing Company.
With more than 30 years of experience in woodworking and metalworking, Sefe sanding machines are well-known brands in the Chinese market, including wide belt sanding machine, paint sanding machine, water sanding machine, double-sided sanding Machine,planer sanding machine, heavy-duty inclined sanding machine and sanding machine production line.
Workshop details display
Machine Assembly Workshop
Rigorous Skilled Workers
Packing&Shipping
Stretch Film or Wooden Packing
Exhibition Show
Certifications
Related Products
Why Choose Us
1. We will come standard with the wearing parts.
2. We accept the 30% TT deposit, machine will be completed within 15 to 20 days delivery.
3. We have specialized technical staff to overseas service.
4. Our warranty period is one year, if you have any questions, please communicate with us promptly.
2. We accept the 30% TT deposit, machine will be completed within 15 to 20 days delivery.
3. We have specialized technical staff to overseas service.
4. Our warranty period is one year, if you have any questions, please communicate with us promptly.
FAQ
Q1:Why is our price more expensive than our peers?
Because we do is high-end products, accessories are high, the cost determines the price.
Q2:What is the Max working width of machine?
We recommend using standard sizes(630/700/1000/1300mm), but all our machines can be customized.
Q3:How long is the shelf life of the product? What to do if something goes wrong?
Our machines are one year shelf life, if problems arise we will allow technical staff to communicate, if necessary, will be on-site service.
Q4:How to cooperate with us?
At present, we already have distributors from many countries. Once we cooperate, we will establish a single trade relationship and work together to safeguard our interests.
Because we do is high-end products, accessories are high, the cost determines the price.
Q2:What is the Max working width of machine?
We recommend using standard sizes(630/700/1000/1300mm), but all our machines can be customized.
Q3:How long is the shelf life of the product? What to do if something goes wrong?
Our machines are one year shelf life, if problems arise we will allow technical staff to communicate, if necessary, will be on-site service.
Q4:How to cooperate with us?
At present, we already have distributors from many countries. Once we cooperate, we will establish a single trade relationship and work together to safeguard our interests.
