hydraulic gear pump for fiat
- Category: >>>
- Supplier: Boden Hydraulics Co. Ltd.
Share on (60789169171):
Product Overview
Description
Product Description
Technical information For BHP2.6A2-R hydraulic gear pump
| Type | Displacement | Max.pressure | Max.speed | Min.speed | ||
| P1 | P2 | P3 | ||||
| cm3/rev | bar | bar | bar | r/min | r/min | |
| BHP2.6A2-D-6-R | 6 | 250 | 280 | 300 | 4000 | 800 |
| BHP2.6A2-D-8-R | 8 | 250 | 280 | 300 | 4000 | 800 |
| BHP2.6A2-D-10-R | 10 | 250 | 280 | 300 | 4000 | 700 |
| BHP2.6A2-D-12-R | 12 | 250 | 280 | 300 | 3500 | 700 |
| BHP2.6A2-D-14-R | 14 | 250 | 280 | 300 | 3500 | 600 |
| BHP2.6A2-D-16-R | 16 | 250 | 280 | 300 | 3500 | 600 |
| BHP2.6A2-D-19-R | 19 | 250 | 280 | 300 | 3000 | 500 |
| BHP2.6A2-D-22-R | 22 | 250 | 280 | 300 | 3000 | 500 |
| BHP2.6A2-D-25-R | 25 | 250 | 280 | 300 | 3000 | 500 |
| BHP2.6A2-D-28-R | 28 | 250 | 280 | 300 | 3000 | 500 |
| BHP2.6A2-D-30-R | 30 | 230 | 250 | 260 | 3000 | 500 |
| BHP2.6A2-D-32-R | 32 | 230 | 250 | 260 | 3000 | 400 |
| BHP2.6A2-D-36-R | 36 | 200 | 230 | 250 | 2750 | 400 |
| BHP2.6A2-D-38-R | 38 | 200 | 230 | 250 | 2750 | 400 |
| BHP2.6A2-D-40-R | 40 | 170 | 190 | 210 | 2500 | 400 |
| BHP2.6A2-D-44-R | 44 | 170 | 190 | 210 | 2500 | 400 |
How to order to order Boden hydraulic gear motor
