S5 высококачественный микроскоп с разрезом и 5 увеличениями
- Category: Medical Optical Instruments >>>
- Supplier: Chongqing Vision Star Optical Co. Ltd.
Share on (60789678558):
Product Overview
Description
S5 High Quality Slit Lamp Microscope with 5 Magnifications
Features:
1. Outstanding Optic Quality Ensure the Comfortable View.
2. Parallel type. Galilean system.
3. LED Illumination, long life time.
4. 5 step magnifications.
5. Haag-Streit type slit lamp with broad beam, wide field and high depth of field.
6. interface for laser and applanation tonometer reserved.
Specifications:
Model | S5 |
Illumination Type | Haag Streit Type |
Illumination Source | Imported LED Lamp |
Max Illumination Intensity | 60000 Lux |
Microscope Type | Parallel type, Galilean system |
Magnification changer | Revolving drum |
Eyepiece | 12.5X |
Magnification | 6X 10X 16X 25X 40X |
Visual field Diameter | 6X:33mm10x:22mm 16X:14mm 25X:8.5mm 40X:5.5mm |
Diopter adjustment | -7D~+7D |
Pupil range | 52mm~82mm |
brightness | continuously adjustable |
Slit image width | 0mm~14mm continuous |
Slit image length | 1mm~14mm continuous |
Slit image angle | 0~180 continuously rotation |
illumination tilting | 5 10 15 20 |
Slit aperture size | 14 10 5 3 1 0.2 (mm) & 1~14mm continuously |
Filter | Heat absorption, Grey, Redfree(Green), Cobalt blue |
Fixation | Red LED 3.5V |
Image collector | None |
Background illumination | None |
Input voltage | 70VA |
Input power | 100V~240V 48~62HZ |
External packing | Carton box |
Dimension | 740”650”450mm |
G/weight | 23kg |
