CPU cooling fan Computer CPU heat sink Downblown aluminum heat dissipation 9225 Fan TX 910 G115X 1200

Product Overview

Description



SPECIFICATION
Model No.	TX-910
Material	Aluminum
Support CPU	I3/I5 all series , INTEL LGA 1155 / 1156/115X/1200
CPU TDP	60W
Voltage	12V
Fan Size	90x90x25mm
Fan RPM	2200±10% RPM
Fan connector	3pin
Cooler Size	95x95x56
Color Box Size	100x100x85mm







FAQ

1. What is a DC Axial Fan?

A DC fan is usually powered by 3v, 5v, 12v, 24v, 36v and 48v. It blows air along the axis of the fan, or parallel to the track of the blade axis. Standard DC Axial fan sizes include 20mm, 30mm, 40mm, 50mm, 60mm, 70mm, 80mm, 92mm,120mm, 150mm, and 200mm.



2. How to choose a DC fan?

To choose a DC fan, you should consider the points below

*fan size(mm):

*fan speed(rpm):

*fan airflow(cfm):

*fan noise level(dBA):

*fan start voltage(v):

*fan current(A):

*fan connector:



3. What is the bearing?

Fan bearing includes Sleeve Bearing, Hydraulic Bearing and Ball Bearing, life expectancy of sleeve bearing fan is 30000 hours, hydraulic bearing fan is 40000 hours , while ball bearing is 55000hours or more.



4. What is the delivery time ?

Sample lead time:2-5 days

Mass production Delivery lead time: 1 -3 weeks

Delivery Ways: DHL, UPS Door to Door service, By Air, By Sea, etc.
