Product Overview

Description



Product Description


Specifications:UB110
Automotive flame retardant wire harness tape with RohS standard
Property
Value
Unit
Test Method
Total thickness
0.11
mm
ASTM-D-1000
Tensile strength
18
N/cm
ASTM-D-1000
Elongation at break
220
%
ASTM-D-1000
Voltage resistance
1kV/min
---
JIS-C2110
PVC backing thickness
95
mic
ASTM-D-1000
Temperature resistance
80
℃
ASTM-D-1000
Flame retardant
B
<2s
ASTM-D-1000
Adhesion strength
-to steel
1.2
N/cm
ASTM-D-1000
-to backing
1.0
N/cm
ASTM-D-1000
Conten of Heavy Metal
·Lead, Cadmium
30
ppm
US EPA3052
·Mercury, Chromium
10
ppm
US EPA3060A
·Polybrominated biphenyl
10
ppm
US EPA3540C
This series wire harness tape is Rohs listed prodcut with B grade flame retardant.
Data in table represent average test results and are not to be used for specification purposes.
The product user should make his/her own tests to determine the product's suitability for the intended use.




Description for Automotive flame retardant wire harness tape with RohS standard.

-Thin premium grade plasticized PVC film backing

-Aggressive rubber based adhesive

-Suitable for continuous use at 80℃

-Good electric resistance

-Soft property

-Chemical substances and humidity resistance

-Complies with RohS requirements

-With flame retardant grade B.



Detailed Images


This series of products are approved by SVW, VOLVO and FAW-VW.

Standard sizes for Automotive flame retartant wire harness tape

Width             Length                Core

19mm            20m                     32mm

19mm            25m                     32mm

Other sizes and cores are available, please contact with us.

Series Products for Automotive flame retardant wire harness tape



Product
code
Total
thickness(μm)
Backing
material
Backing
thickness(μm)
Tensile
strength(N/cm)
Elongation (%)
180° peel of strength
To steel(N/cm)
180° peel of strength
To backing(N/cm)
Voltage
Resistance
Continuous operating
temperature (℃)
UB085
85
PVC
75
16
200
1.2
1.0
1kV/min
80
UB100
100
PVC
85
17
210
1.2
1.0
1kV/min
80
UB110
110
PVC
95
18
220
1.2
1.0
1kV/min
80
UB120
120
PVC
105
19
220
1.2
1.0
1kV/min
80
UB130
130
PVC
115
21
230
1.2
1.0
1kV/min
80
UB150
150
PVC
135
23
250
1.2
1.0
1kV/min
80
UB180
180
PVC
165
28
250
1.2
1.0
1kV/min
80
UB280
280
PVC
265
35
250
1.0
1.0
1kV/min
80
Complies with ROSH requirements and flame retardant grade B.


Recommended uses for Automotive flame retardant wire harness tape

Used as permanent wrapping on cables and wiring harnesses for automobile.

Used in the wrapping and protection of automotive wire harnesses

The recommended application method is with a 50% overlap and don't apply over tension at last layer.



Packing & Delivery




We could provide Individual package with label and 10rolls/shrink, 60roll/ctn

Economical package, 10 or 6 per plastic film coil.

The OEM package is available, please contact with me.
