Advantages of XBPA brand broadcasting PA system
1: PA system is directly embedded in IP network without large amount of wiring of analog broadcasting system
2: PA system is arbitrarily/infinitely partitioned, and different contents can be played in different areas at the same time
3. Multi-task preset management mode to realize 24/7 unattended operation
4. Support remote transmission and centralized control across gateways
5. Powerful management software to meet full-featured real-time broadcast control and system management
6: There is no equipment for sub-control, only sub-control software needs to be added to the sub-control computer, which is simple and does not require wiring,
7: PA system can set up multiple priorities: Emergency Broadcasting, network broadcasting and local broadcasting

XBPA public broadcasting system advantages
The network is embedded directly into the IP network without the need to simulate a large number of wiring in the broadcast system
Flexible/infinite partitioning allows different areas to play different content at the same time
Launched multi-task preset management mode to realize all-weather unattended
Supports remote transmission across gateways and centralized control
Is a powerful management software to meet the full function of real-time broadcast control and system management
We only need additional point control software on the computer. It is simple and requires no wiring.
PA Systems can have multiple priorities: emergency, network, local
Any single point play: can broadcast to any single point, group, partition, or all.
The system can set up any number of groups to play the specified audio program at the same time, or broadcast any designated area.
Automatic music ring: can set personalized music ring tone, and play the ring tone according to the arranged schedule.
The schedule can be adjusted according to spring and autumn.
Remote subcontrol of speech: remote control of broadcast can be achieved through any computer connected to the server without going to the broadcast center.
In this way, leaders or teachers can talk to the whole district, sub-district and group remotely.
Multi-channel real-time collection and broadcasting: it can collect real-time programs such as self-use radio station, cassette recorder, CD player, MP3 player, microphone and so on, and compress them into high quality data stream and store them on the server, and transmit them to the designated broadcasting terminal at the same time as required, for playing external equipment broadcasting and broadcasting notice.
Single multi-channel sound card can be supported.
Classroom free on demand: the teacher can control the broadcast terminal distributed in each classroom through the remote control or the key to complete arbitrary on demand in the server database, can fast forward, fast reverse, pause and AB two point reread.
Terminal LCD display database directory and current playing position.
Timed program broadcast: each broadcast terminal can receive the personalized timed program from the server separately for voice training, etc. Teachers can set the program remotely on the Internet or press the button on the terminal directly.
Network radio broadcast: Internet network radio programs received through network radio software can be converted into IP network broadcast data format for real-time broadcast of broadcast terminals, such as some special language radio stations.
Paging intercom function (optional) : the terminal can call other single or multiple terminals, and it can also conduct two-way intercom between terminals.
In this way, the office can broadcast to any area of the campus, and communicate with each other between offices, classrooms, and between offices and classrooms.
Broadcast monitoring: in the broadcast management center, all broadcast programs can be monitored in real time.
Alarm broadcast linkage (optional) : the alarm linkage function can be performed by pre-setting alarm mode on the server software after receiving alarm signals from the network alarm host.
Wireless remote control (optional) : it can control broadcast programs required by activities such as flag-raising at the playground rostrum by remote wireless remote control.
Telephone access control (optional) : it can control the broadcast speech by calling the phone, so that the leader can issue the emergency broadcast notice at any time even if he is not on campus.
model | XBPA-5300 |
The network interface | Standard RJ45 input. |
Support agreement | TCP/IP, UDP, IGMP (multicast) |
Audio formats | MP3 / MP2 |
Sampling rate | 8 k-48 KHZ |
Transmission rate | 100 MBPS |
Audio mode | 16 bit stereo CD quality. |
Audio source output level. | 2 road 1000mV output industrial standard voltage line terminals. |
Audio source output impedance. | 470 Ω |
Frequency response | 20 HZ to 20 KHZ |
Kai wave distortion | THD 0.3% or less |
Signal to noise ratio | > 65 db |
AUX input sensitivity | 350mV input industrial standard voltage line terminals. |
MIC input sensitivity | 5 MV |
Working temperature | 5 ℃ to 40 ℃ |
The net weight | 3.2 Kg |



Campus broadcast system | public broadcast |IP network broadcast system | paperless conference system | professional sound amplification system | digital conference system |4G wireless broadcast system |IP network visible intercom | broadcast amplifier |IP broadcast terminal |IP network speaker |0 4G network sound column







XBBA is one of the earliest manufacturers of public broadcasting system, digital conference system, professional sound reinforcement system, central control system, remote video conference system, HD recording and broadcasting system, family background music system and remote interactive teaching system in China.
scale
Supporting production includes: electronic workshop, high-tech product workshop, all-digital conference system workshop, wireless wheat workshop, speaker workshop, professional audio workshop, hardware workshop, woodworking workshop, spraying workshop, FRP workshop, surface treatment oxidation workshop.
research and development
High-tech Development Department/Conventional Product Development Department/Personalized Product Customization Development Department
system
Six core systems:
1. HD remote video conferencing system.
2. Full digital conference system + paperless multimedia conference system + conference sound reinforcement system.
Three. Full Digital Public Broadcasting System + Full Digital Fire Broadcasting System.
4. Distributed mosaic processing system.
5. Central control matrix system.
6. Full HD Recording and Broadcasting System + Educational Cloud Platform.
application
Each system focuses on different professional industries, including schools, gymnasiums, buildings, intelligent buildings, hotels, banks, prisons, real estate, commercial real estate, Park Square pedestrian street, companies, factories, enterprises and institutions, hospital supermarkets, terminal airports, entertainment and leisure, etc. E venue, exhibition hall, government units, etc.
prerequisites
The company has passed ISO 9001 quality certification, 14001 environmental certification, 18001 occupational health certification, 27001 Information Technology Security certification, CCCF fire protection certification, 3C certification and other certification, and constantly meet the global certification requirements.
Price
"High cost performance" is our consistent pursuit.
logistics
The year-round inventory of finished products is 45 days. We guarantee delivery within 10 days of normal system.



New products from manufacturers at wholesale prices
