Product Overview
Description
Product Description
Fine finished steel gears,Hi-resistant Extruded alluminum body, Hi-resistant Die cast alluminum cover(BAP2) or cast-iron cover(BHP2), Low-friction die casting alluminum bushes,and DU slide bearing,all these keep low pulsation,low noise and long life.
Technical information For BHP2A0-R hydraulic gear pump
| Type | Displacement | Max.pressure | Max.speed | Min.speed | ||
| P1 | P2 | P3 | ||||
| cm3/rev | bar | bar | bar | r/min | r/min | |
| BHP2A0-D-3-R | 3 | 270 | 285 | 300 | 4000 | 800 |
| BHP2A0-D-4-R | 4 | 270 | 285 | 300 | 4000 | 600 |
| BHP2A0-D-6-R | 6 | 270 | 285 | 300 | 4000 | 600 |
| BHP2A0-D-8-R | 8 | 270 | 285 | 300 | 3500 | 500 |
| BHP2A0-D-10-R | 10 | 270 | 285 | 300 | 3000 | 500 |
| BHP2A0-D-12-R | 12 | 270 | 285 | 300 | 3000 | 500 |
| BHP2A0-D-14-R | 14 | 250 | 265 | 280 | 4000 | 500 |
| BHP2A0-D-16-R | 16 | 250 | 265 | 280 | 4000 | 500 |
| BHP2A0-D-18-R | 18 | 250 | 265 | 280 | 3600 | 400 |
| BHP2A0-D-20-R | 20 | 220 | 235 | 250 | 3200 | 400 |
| BHP2A0-D-22-R | 22 | 220 | 235 | 250 | 3000 | 400 |
| BHP2A0-D-25-R | 25 | 200 | 215 | 230 | 3000 | 400 |
| BHP2A0-D-28-R | 28 | 180 | 190 | 200 | 2500 | 400 |
| BHP2A0-D-30-R | 30 | 160 | 170 | 180 | 2500 | 400 |
How to order to order Boden hydraulic gear motor
Product Application
