380V CE Certificate leisuwash 360 automatic car wash touch free with certification

Product Overview

Description

380V CE Certificate leisuwash 360 automatic car wash touch free with certification



Product description

Touchless car washing machine is suitable for cars, jeeps, mini van, box type vehicle cleaning, washing, in addition to the chassis and related water treatment equipment.



System components

1. The host rack.

2. Travel system.

3. The side swing high pressure water cleaning system.

4. Foam water and wax water supply system.

5. Towline stent system.

6. The electrical control system.



Technical data



Machine size	3500*1200*900
Water pump size	1250*800*600
Chemical mixing system size	800*450*1400
Rail length	6800~7500
Shipment weight / Volume	2.6 Ton, 11CBM
Mounting Dimensions (ceiling mounting length)	6600~7500
Mounting Dimensions (floor mounting length)	≥7600
Mounting Dimensions (ceiling mounting width)	≥3600
Mounting Dimensions (floor mounting width)	≥3850
Mounting Dimensions (height)	≥3350
Power Requirements	380V/22Kw, 50Hz/60Hz
Air	80A
Total power	22kw
Water pump motor power	15kw
Fan motor power	20.5Kw / full pressure 11000Pa / air volume 23000 cubic meters / h
Longitudinal motor power	0.37Kw stepless frequency control
Transversal motor power	0.75Kw digital drive motor
Rotary motor power	0.75Kw digital drive motor
Liquid proportioning system motor power	0.75kw
Central processor	Industrial PLC embedded central processor + dual-core system
Drive System	Promise frequency digital drive
Detection system	Smart three-dimensional monitoring system
Sensing System	Ultrasound+ Absolute value of the digital encoder
Speed	360 wash 28 seconds, energy saving 60%
Wash liquid consumption	Depends on liquid proportioning
Polish shampoo consumption	10ml-40ml
Crystal wax coating consumption	18.5L could apply for 1000 cars
Water consumption	Standard wash 94L/car, Fine wash 150L/car
Electricity consumption	Standard wash 0.52 kW·h/car, Fine wash 0.99 kW·h/car

Product details





Company information

    Yancheng Honzo Marchinery&Equipment Co.,Ltd. Located in Yancheng city-Jiangsu province, is specialized in developing, producing and marketing the auto service equipment, coating equipment, vehicle washing machine and so on. Our founder entered the auto service industry from Augest 1999, researched and developed kinds of new products. Then in the recent years, we imported the advanced technology to creat the Honzo Brand series products.



FAQ

1. Why the price is so low?

    You are ordering directly from the factory.

2.Where is your factory located? How can I visit there?

    Our factory is located in Yancheng City, Jiangsu Province, China,about

4 hours bus ride from Shanghai .All our clients, from home or abroad, are warmly welcome to visit us.

3.What type of payment do you have available?

    We accept TT and L/C, the Western Union,Money gram and Aliexpress is available.

4.How does your factory do regarding quality control?
   "Clients orientation, Quality first, Advanced technology and Continuous development”. Honzo people always attach great importance to quality controlling

from the very beginning to the very end.
