medical lens Nd: YAG/Alex laser lens tattoo removal 1064nm 532nm etc RONAR SMITH
- Category: Lenses >>>
- Supplier: Nanjing Wavelength Opto-Electronic Science & Technology Co. Ltd.
Share on (60791099235):
Product Overview
Description
Product Description
Product Description
Specifications
Diameter Tolerance: +0/-0.2mm Thickness Tolerance: ±0.2mm
FL Tolerance: <+/-2%
Paraxial Focal Length: ±2%
Centration: 3 arc minutes
Clear Aperture >80%
Surface Figure: λ/4 per 25mm Dia @632.8nm
Surface Quality: 60-40 scratch and dig
Part no | Dis(mm) | EFL(mm) | ET(mm) | Material | Wavelength | applicance | |
LBK-0.5-20-ET2 | 12.7 | 20.0 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-15-25-ET2 | 15.0 | 25.0 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-1-37.1-ET2 | 25.4 | 37.1 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-1-40-ET2 | 25.4 | 40.0 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-1-50-ET2 | 25.4 | 50.0 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-1-2-ET2. | 25.4 | 50.8 | 2.0 | BK7 | 1064nm | Nd:YAG | |
LBK-12-24-ET1.5 AY | 12.0 | 24.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
LBK-12-30-ET1.5 AY | 12.0 | 30.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
LBK-12-48-ET1.5 AY | 12.0 | 48.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
LBK-15-30-ET1.5AY | 15.0 | 30.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
LBK-15-75-ET1.5 AY | 15.0 | 75.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
LBK-18-36-ET1.5AY | 18.0 | 36.0 | 1.5 | BK7 | 1064 / 755nm | Nd:YAG / Alex | |
.
.
.
.
.
.
